The IRAM256-2067A2 is a 20A, 600V integrated power hybrid IC (IGBT) from Infineon Technologies, designed for 3-phase appliance motor drive applications.
This module integrates gate drivers, bootstrap diodes, and protection features in a compact through-hole PowerSSIP module, offering a space-saving solution for variable-speed motor drives.
Key electrical specifications include a maximum collector-emitter blocking voltage (VCES) of 600V, a maximum RMS phase current of 20A at TC=25°C and 10A at TC=100°C, and a maximum power dissipation per IGBT of 34W at TC=25°C. It operates over a junction temperature range of -40°C to +150°C, with a maximum case temperature of 125°C. The module also features a minimum isolation voltage of 2000 Vrms and a maximum PWM carrier frequency of 20 kHz, supporting motor power up to 1.5 kW.
The device is packaged in a 29-PowerSSIP module with 21 formed leads, suitable for through-hole mounting. Its built-in temperature monitor and protection features enhance reliability in demanding environments.
The maximum RMS phase current is 20 A at TC=25°C and 10 A at TC=100°C.
The maximum collector-emitter blocking voltage (VCES) is 600 V.
The operating junction temperature range is -40°C to +150°C.
The device is packaged in a 29-PowerSSIP Module with 21 leads, formed leads, for through-hole mounting.
The minimum isolation voltage is 2000 Vrms (test condition: 1 min).
The module supports motor power up to 1.5 kW (85~253 Vac).
