| Distributor | Stock | Pricing | MOQ | PKG | Lead Time | Date Code | On Order Quantity | On Order Delivery | |
|---|---|---|---|---|---|---|---|---|---|
|
2,006 pcs
|
2006 pcs | On Request | 1 | On Request | On Request | On Request | On Request | On Request |
| Category | |
| Manufacturer Name | |
| Applications | |
| Current | |
| Mounting Type | |
| Operating Temperature | |
| Operating Voltage | |
| Quiescent Current | |
| Supplier Device Package | |
| Tape & Reel | |
| Voltage |
The Infineon Technologies IR11688STRPBF is a dual synchronous rectification controller IC designed for secondary-side control in resonant half-bridge converters. It is optimized to drive N-channel power MOSFETs, emulating Schottky diode behavior to minimize power dissipation.
Key electrical specifications include a wide Vcc operating range of 4.75V to 18V and the ability to operate up to 400kHz switching frequency. It features a 4A peak turn-off drive current and a 50ns turn-off propagation delay. The controller directly senses MOSFET drain voltage up to 200V.
This IC is housed in an 8-SOIC package suitable for surface mounting. Its features include programmable minimum on-time, anti-bounce logic, UVLO protection, and cycle-by-cycle MOT protection, making it suitable for applications like desktop SMPS, server SMPS, AC-DC adapters, and telecom SMPS.
Typical applications include desktop SMPS, server SMPS, AC-DC adapters, LCD & PDP TVs, and telecom SMPS. The device is designed for improved noise immunity and compatibility with low standby power requirements.
| Qty | Low | High |
|---|---|---|
| 1+ | $0.75 | $0.75 |
Estimated market price range - modelled values for guidance only, not live distributor offers.
The operating voltage range is 4.75V to 18V.
The operating temperature range is -40°C to 125°C.
It comes in an 8-SOIC surface mount package.
The maximum switching frequency is 400kHz.
The typical quiescent current is 13mA.
The peak turn-off drive current is 4A.
