Mfr Part #:

IPT026N10N5

Mfr Name: Infineon

The Infineon IPT026N10N5 is a 100V N-channel MOSFET designed for high-frequency switching applications. It offers low on-resistance and high current capabilities.

✓ Total Stock: 1,543 pcs

IPT026N10N5 Available from 1 distributor

✓ Authorised

✓ Non-Authorised

Distributor		Stock	Pricing	MOQ	PKG	Lead Time	Date Code	On Order Quantity	On Order Delivery
Xingangxin ✓ Non-Authorised Inventory information	1,543 pcs On Request	1543 pcs	On Request	1	On Request	On Request	On Request	On Request	On Request

IPT026N10N5 Specifications Quick View

Most important parameters for selection – full specs in datasheet.

SELECT ALL

Category	New Products
Manufacturer Name	Infineon
Gate Charge	96 nC
Halogen Free	Halogen-free
Mounting Type	Surface Mount
Package / Case	PG-HSOF-8
Power Dissipation	214 W
SVHC Present	Not Present

View Similar Products (0)

IPT026N10N5 Description

Short technical summary and product information.

The Infineon IPT026N10N5 is an OptiMOSTM 5 series N-channel MOSFET with a drain-source voltage rating of 100V. It is engineered for high-frequency switching and synchronous rectification applications, offering an excellent figure of merit (FOM) due to its low on-resistance.

Key electrical characteristics include a maximum on-resistance of 2.6 mΩ at VGS=10V and ID=202A, and a continuous drain current of 202A at 25°C case temperature. The device is 100% avalanche tested and features a gate charge of 96 nC and output charge of 123 nC.

Packaged in a PG-HSOF-8 surface-mount package, the IPT026N10N5 is suitable for industrial applications. It is Pb-free and halogen-free, complying with RoHS standards. The operating temperature range is -55°C to 175°C.

This MOSFET is fully qualified according to JEDEC standards for industrial applications, making it a reliable choice for power management solutions.

IPT026N10N5 Quick Information

Product Type: N-Channel MOSFET

Series: OptiMOS

Canonical Name: Infineon OptiMOSTM 5 Power Transistor, 100 V, N-channel

Subcategory: N-Channel

IPT026N10N5 Compliance

RoHS Status: RoHS Compliant

Moisture Sensitivity Level (MSL): 1 Unlimited

REACH Status: REACH Unaffected

Lead Free: Yes

IPT026N10N5 Features

100V drain-source voltage rating.
Low on-resistance: 2.6 mΩ maximum.
High continuous drain current: 202A.
N-channel, normal level MOSFET.
Pb-free and halogen-free.

IPT026N10N5 Applications

Ideal for high-frequency switching.
Suitable for synchronous rectification.
Designed for industrial applications.
Power management solutions.

IPT026N10N5 FAQs

7 frequently asked questions generated from this part’s specifications.

What is the maximum drain-source voltage for the IPT026N10N5?

The maximum drain-source voltage (VDS) for the IPT026N10N5 is 100 V.

What is the maximum on-resistance of the IPT026N10N5?

The maximum on-resistance (RDS(on)) is 2.6 mΩ when VGS is 10 V and ID is 202 A.

What is the continuous drain current rating at 25°C?

The continuous drain current (ID) is rated at 202 A at 25°C case temperature with VGS=10 V.

What package type is the IPT026N10N5 supplied in?

The IPT026N10N5 is supplied in the PG-HSOF-8 package.

Is the IPT026N10N5 RoHS compliant?

Yes, the IPT026N10N5 is RoHS3 Compliant.

What is the Moisture Sensitivity Level (MSL) for this part?

The Moisture Sensitivity Level (MSL) is 1 Unlimited.

Does the IPT026N10N5 meet REACH requirements?

The REACH Status is Unaffected.
