The IPD95R750P7ATMA1 is a 950V N-Channel enhancement mode power MOSFET from Infineon's CoolMOS P7 super junction series. It combines best-in-class figure of merit (RDS(on)*Eoss) with ease of use, featuring a low typical gate charge of 23 nC and input capacitance of 712 pF. The device integrates a Zener diode for ESD protection (HBM class 2) and offers a tight threshold voltage variation of ±0.5V around a typical 3V.
Key electrical specifications include a maximum drain-source voltage of 950V, continuous drain current of 9A, and maximum on-resistance of 750 mOhm at Vgs=10V. The MOSFET can dissipate up to 73W and operates over a junction temperature range of -55°C to 150°C.
This device is recommended for flyback topologies in LED lighting, low power chargers and adapters, smart meters, AUX power supplies, and industrial power applications. It is also suitable for power factor correction (PFC) stages in consumer and solar applications.
The IPD95R750P7ATMA1 is supplied in a PG-TO252-3 (DPak) surface-mount package with gull wing leads, enabling compact and efficient PCB assembly.
| Qty | Low | High |
|---|---|---|
| 1+ | $2.78 | $2.78 |
| 10+ | $1.79 | $1.79 |
| 100+ | $1.22 | $1.22 |
| 500+ | $1.03 | $1.03 |
| 1,000+ | $0.91 | $0.91 |
| 2,500+ | $0.84 | $0.84 |
| 5,000+ | $0.83 | $0.83 |
Estimated market price range - modelled values for guidance only, not live distributor offers.
The maximum drain-source voltage is 950V.
It is available in a TO-252-3 (DPak) surface-mount package.
The operating junction temperature range is -55°C to 150°C.
The part is listed as RoHS3 compliant, but this status is unverified.
The typical gate charge is 23 nC at Vgs=10V.
The maximum on-resistance is 750 mOhm at Id=4.5A and Vgs=10V.
It has integrated ESD protection with an HBM class of 2.
