| Distributor | Stock | Pricing | MOQ | PKG | Lead Time | Date Code | On Order Quantity | On Order Delivery | |
|---|---|---|---|---|---|---|---|---|---|
|
475 pcs
|
475 pcs | On Request | 1 | On Request | On Request | N/A | On Request | On Request |
| Category | |
| Manufacturer Name | |
| Connector Type | |
| Contact Finish | |
| Contact Length | |
| Contact Material | |
| Contact Shape | |
| Contact Type | |
| Current Rating (Amps) | |
| Fastening Type | |
| Insulation Color | |
| Insulation Height | |
| Insulation Material | |
| Lead Spacing | |
| Lead Style | |
| Material Flammability Rating | |
| Mounting Type | |
| Number of Positions | |
| Number of Positions Loaded | |
| Number of Rows | |
| Operating Temperature | |
| Pitch | |
| Shrouding | |
| Style | |
| Tape & Reel | |
| Termination | |
| Voltage Rating |
The IL-S-6P-S2T2-EF is a rectangular connector header designed for board-to-cable/wire applications. It has 6 positions in a single row with a 2mm pitch. The connector is shrouded with a 4-wall design, providing protection for the male pins. It features a detent lock fastening type for secure mating. The insulation is made of polyamide (PA66/Nylon 6/6) with a brown color and a flammability rating of UL94 V-0. The operating temperature range is -40°C to 85°C. The contacts are made of brass with a tin finish, square shape, male pin type. The current rating is 3A per contact, and the voltage rating is 300VAC/400VDC. The mounting type is through hole with kinked pin, solder termination. The insulation height is 5.51mm and contact length is 3.50mm.
6 positions in a single row.
2.00mm (0.079 inches).
3A per contact.
300VAC/400VDC.
Through hole with kinked pin, solder termination.
-40°C to 85°C.
Polyamide (PA66), Nylon 6/6 with UL94 V-0 flammability rating.
