Mfr Part #:

IKW75N60T

Mfr Name: Infineon

The Infineon IKW75N60T is an IGBT with a 600V collector-emitter voltage and 75A continuous collector current. It features a maximum junction temperature of 175°C and a low VCE(sat) of 1.5V typical.

✓ Total Stock: 9,833 pcs

$ Price Range: $1.67

IKW75N60T Available from 3 distributors

✓ Authorised

✓ Non-Authorised

Distributor		Stock	Pricing	MOQ	PKG	Lead Time	Date Code	On Order Quantity	On Order Delivery
Xingangxin ✓ Non-Authorised Inventory information	6,251 pcs On Request	6251 pcs	On Request	1	On Request	On Request	On Request	On Request	On Request
Optech Co.,Limited ✓ Non-Authorised Inventory information	1,791 pcs On Request	1791 pcs	On Request	1	On Request	On Request	24+	On Request	On Request
Smaxon Electronics ✓ Non-Authorised Inventory information	1,791 pcs On Request	1791 pcs	On Request	1	On Request	On Request	24+	On Request	On Request

IKW75N60T Specifications Quick View

Most important parameters for selection – full specs in datasheet.

SELECT ALL

Category	New Products
Manufacturer Name	Infineon
Input Capacitance	4620pF
Lead Spacing	2.54 mm
Mounting Type	Through Hole
Power Dissipation	428W
Storage Temperature	-55°C ~ 150°C
Tape & Reel	No

View Similar Products (0)

IKW75N60T Description

Short technical summary and product information.

The Infineon IKW75N60T is an IGBT from the TRENCHSTOP™ Series, utilizing TRENCHSTOP™ and Fieldstop technology for efficient performance. It offers a 600V collector-emitter voltage and a continuous collector current of 75A at 25°C case temperature, with a pulsed capability up to 225A.

Key electrical characteristics include a low typical VCE(sat) of 1.5V at 25°C and 1.9V at 175°C, along with a fast recovery anti-parallel Emitter Controlled HE diode. The device operates over a junction temperature range of -40°C to +175°C, with a maximum power dissipation of 428W at 25°C.

This IGBT is packaged in a PG-TO247-3 through-hole package. It is designed for applications such as frequency converters and uninterruptible power supplies (UPS), offering high ruggedness and temperature-stable behavior. The component is Pb-free and RoHS compliant.

Additional specifications include a short circuit withstand time of 5µs and thermal resistance values such as 0.35 K/W for junction-to-case.

IKW75N60T Quick Information

Product Type: IGBT

Series: TRENCHSTOP™ Series

Canonical Name: IKW75N60T IGBT

Subcategory: Insulated Gate Bipolar Transistor

IKW75N60T Compliance

RoHS Status: RoHS Compliant

Moisture Sensitivity Level (MSL): 1 Unlimited

REACH Status: REACH Unaffected

Lead Free: Pb-free lead plating

IKW75N60T Estimated Pricing

Qty	Low	High
1+	$1.67	$1.67

Estimated market price range - modelled values for guidance only, not live distributor offers.

IKW75N60T Features

600V collector-emitter voltage rating.
75A continuous collector current.
175°C maximum junction temperature.
Low VCE(sat) of 1.5V typical.
Fast recovery anti-parallel diode.

IKW75N60T Applications

Ideal for frequency converters.
Suitable for uninterruptible power supplies.
Used in high-speed switching circuits.
Power factor correction applications.

IKW75N60T FAQs

6 frequently asked questions generated from this part’s specifications.

What is the maximum collector-emitter voltage for the IKW75N60T?

The maximum collector-emitter voltage (Vce) for the IKW75N60T is 600V.

What is the continuous collector current rating?

The continuous collector current (Ic) is rated at 75A at 25°C case temperature.

What is the maximum operating junction temperature?

The maximum operating junction temperature (Tj) is 175°C.

What is the typical collector-emitter saturation voltage?

The typical collector-emitter saturation voltage (VCE(sat)) is 1.5V at 25°C.

What type of package is the IKW75N60T in?

The IKW75N60T is supplied in a PG-TO247-3 package.

What are the main applications for this IGBT?

This IGBT is suitable for applications such as frequency converters and uninterruptible power supplies.
