| Distributor | Stock | Pricing | MOQ | PKG | Lead Time | Date Code | On Order Quantity | On Order Delivery | |
|---|---|---|---|---|---|---|---|---|---|
|
1 pcs
|
1 pcs | On Request | 1 | On Request | On Request | On Request | On Request | On Request |
| Category | |
| Manufacturer Name | |
| Efficiency | |
| Input Frequency | |
| Input Voltage | |
| Output Current | |
| Output Voltage | |
| Overload Protection | |
| Stability | |
| Storage Temperature |
The International Power IHC5-6/OVP is an open-frame linear power supply designed for versatile use with global AC power sources. It delivers a stable 5 VDC output at a maximum current of 6 A. This model incorporates essential protection features including overvoltage protection factory set at 6.2VDC +/- 0.4VDC, automatic foldback for short circuit protection, and automatic current limiting for overload protection.
Designed for efficiency and reliability, the IHC5-6/OVP operates with a typical efficiency of 50% and offers excellent line and load regulation of +/- 0.05%. It features a low output ripple of 5.0mV pk-pk and a fast transient response of less than 50 µsec. The operating temperature range is from 0°C to 50°C, with derating to 40% at 70°C, and storage temperatures from -40°C to +85°C.
This power supply meets stringent environmental and safety standards, including EMI/RFI compliance with FCC CFR Title 47 Part 15 Sub-Part B and EN55022/CISPR22-Level B. It is UL recognized for US and Canada (File#E133338) and carries the CE Mark for LVD 92/59/EEC. The unit is manufactured in the U.S.A. and is RoHS3 compliant with a lead-in-solder exemption.
| Qty | Low | High |
|---|---|---|
| 1+ | $0.99 | $0.99 |
Estimated market price range - modelled values for guidance only, not live distributor offers.
The IHC5-6/OVP provides a 5 VDC output at 6 A.
The power supply supports input voltages of 100, 120, 220, 230, and 240 VAC.
It includes overvoltage protection set at 6.2VDC +/- 0.4VDC, automatic foldback short circuit protection, and automatic current limit overload protection.
The operating temperature range is 0°C to 50°C, derated linearly to 40% at 70°C.
Yes, remote sensing is provided.
It complies with EMI FCC CFR Title 47 Part 15 Sub-Part B and RFI EN55022/CISPR22-Level B.
