| Distributor | Stock | Pricing | MOQ | PKG | Lead Time | Date Code | On Order Quantity | On Order Delivery | |
|---|---|---|---|---|---|---|---|---|---|
|
3,235 pcs
|
3235 pcs | On Request | 1 | On Request | On Request | On Request | On Request | On Request | |
|
1,000 pcs
|
1000 pcs | On Request | 1 | On Request | On Request | 16+ | On Request | On Request | |
|
725 pcs
|
725 pcs | On Request | 1 | On Request | On Request | 1641+ | On Request | On Request |
| Category | |
| Manufacturer Name | |
| Lead Spacing | |
| Lead Style | |
| SVHC Present | |
| Storage Temperature |
The Infineon IDW75E60 is a fast switching emitter controlled diode designed with EmCon technology. It offers a repetitive peak reverse voltage of 600V and a continuous forward current rating of 120A at 25°C case temperature, decreasing to 75A at 100°C.
Key electrical characteristics include a low forward voltage of 1.65V at 75A and 25°C, and a maximum junction operating temperature of 175°C. The diode exhibits fast recovery times, low reverse recovery charge, and soft switching capabilities.
With a thermal resistance junction-to-case of 0.5 K/W, the IDW75E60 is suitable for applications requiring efficient power handling. It is packaged in a PG-TO247-3 package.
Applications for this diode include welding and motor drives, where its fast switching and robust performance are beneficial.
| Qty | Low | High |
|---|---|---|
| 1+ | $3.63 | $3.63 |
Estimated market price range - modelled values for guidance only, not live distributor offers.
The repetitive peak reverse voltage (VRRM) is 600V.
The continuous forward current is 120A at 25°C, 82A at 90°C, and 75A at 100°C.
The maximum junction operating temperature is 175°C.
The IDW75E60 is supplied in a PG-TO247-3 package.
The RoHS status is RoHS3 Compliant.
The Moisture Sensitivity Level is 1 Unlimited.
The typical diode forward voltage at 75A and 25°C is 1.65V.
