Mfr Part #:

IDG666-1-63F-15.0-01

Mfr Name: Sensata

The Sensata IDG666-1-63F-15.0-01 is a 1-pole magnetic hydraulic delay circuit breaker. It features a 15A current rating and a 250V voltage rating.

Stock on Request

IDG666-1-63F-15.0-01 Description

Short technical summary and product information.

This Sensata IDG666-1-63F-15.0-01 is a single-pole circuit breaker designed for panel mounting. It utilizes a magnetic hydraulic delay mechanism for reliable operation.

The breaker has a current rating of 15A and a voltage rating of 250V. It is equipped with a lever actuator for easy operation and is approved by UL1077.

This component is suitable for applications requiring overcurrent protection with a specific delay characteristic. Its panel mount design facilitates integration into various electrical enclosures and systems.

IDG666-1-63F-15.0-01 Quick Information

Product Type: Circuit Breaker

Series: IDG666

Canonical Name: Sensata IDG666-1-63F-15.0-01 Magnetic Hydraulic Delay Circuit Breaker

Subcategory: Magnetic Hydraulic Delay

IDG666-1-63F-15.0-01 Compliance

RoHS Status: RoHS Compliant

Moisture Sensitivity Level (MSL): 1 Unlimited

REACH Status: REACH Unaffected

IDG666-1-63F-15.0-01 Features

15A current rating for protection.
250V voltage rating for circuits.
Magnetic hydraulic delay mechanism.
Panel mount with lever actuator.
UL1077 approval agency recognized.

IDG666-1-63F-15.0-01 Applications

Provides overcurrent protection.
Suitable for panel mounting.
Used in electrical control systems.
Offers controlled tripping delay.

IDG666-1-63F-15.0-01 FAQs

7 frequently asked questions generated from this part’s specifications.

What is the current rating of the Sensata IDG666-1-63F-15.0-01?

The current rating is 15A.

What is the voltage rating of this circuit breaker?

The voltage rating is 250V.

What type of breaker is the IDG666-1-63F-15.0-01?

It is a magnetic hydraulic delay circuit breaker.

How many poles does this circuit breaker have?

It is a single pole breaker.

What actuator type does this breaker use?

It uses a lever actuator.

What is the mounting type for this component?

It is designed for panel mount installation.

What safety approvals does the IDG666-1-63F-15.0-01 carry?

It is UL1077 approved.
