| Distributor | Stock | Pricing | MOQ | PKG | Lead Time | Date Code | On Order Quantity | On Order Delivery | |
|---|---|---|---|---|---|---|---|---|---|
|
3 pcs
|
3 pcs | On Request | 1 | On Request | On Request | 1240+ | On Request | On Request |
| Category | |
| Manufacturer Name | |
| Data Rate | |
| ESD Protection | |
| Lead Spacing | |
| Lead Style | |
| Mounting Type | |
| Operating Temperature | |
| Receiver Hysteresis | |
| Slew Rate | |
| Supply Voltage |
The ICL3232CBNZ is a 3.0V to 5.5V powered RS-232 transceiver that meets EIA/TIA-232 and V.28/V.24 specifications. It is designed for applications requiring low power consumption, such as PDAs, Palmtops, and notebook computers.
Key electrical specifications include a wide supply voltage range of 3V to 5.5V and a guaranteed minimum data rate of 250kbps. The device also features receiver hysteresis for improved noise immunity and a low supply current of 1µA in the powerdown state. It operates within a temperature range of 0°C to 70°C.
The ICL3232CBNZ is supplied in a 16-SOIC surface mount package, making it suitable for space-constrained designs. It is compatible with 3.3V and 5.0V systems.
This transceiver is a drop-in replacement for several Maxim Integrated and MaxLinear parts, including MAX3221, MAX3222, MAX3223, MAX3232, MAX3241, MAX3243, and SP3243. It also serves as a low-power upgrade for older parts like ICL232 and HIN232.
| Qty | Low | High |
|---|---|---|
| 1+ | $2.14 | $2.14 |
Estimated market price range - modelled values for guidance only, not live distributor offers.
The supply voltage range is 3V to 5.5V.
The maximum data rate is 250kbps.
The operating temperature range is 0°C to 70°C.
It is available in a 16-SOIC surface-mount package (0.154", 3.90mm Width).
Yes, it features 15kV ESD protection (Human Body Model).
The maximum supply current in powerdown state is 1µA.
