| Distributor | Stock | Pricing | MOQ | PKG | Lead Time | Date Code | On Order Quantity | On Order Delivery | |
|---|---|---|---|---|---|---|---|---|---|
|
2,252 pcs
|
2252 pcs | On Request | 1 | On Request | On Request | 09+ | On Request | On Request |
| Category | |
| Manufacturer Name | |
| Control Features | |
| Duty Cycle | |
| Internal Switch(s) | |
| Mounting Type | |
| Operating Temperature | |
| Output Isolation | |
| Power (Watts) | |
| Topology | |
| Voltage |
The Infineon ICE3B3565P is an offline controller IC for Switched-Mode Power Supplies (SMPS) with OTP (One-Time Programmable) functionality. It operates within a supply voltage range of 8.5V to 21V and boasts a breakdown voltage of 650V.
Key electrical specifications include a maximum power output of 170W, a switching frequency of 67kHz, and a duty cycle of up to 72%. The device incorporates essential control features such as soft start, current limiting, open loop, overload, over-temperature, and over-voltage protection. It also has a startup voltage of 15V and provides isolated output.
Packaged in a PG-TO220-6 case, the ICE3B3565P is designed for through-hole mounting. The operating temperature range is from -25°C to 130°C (TJ). This component is classified under Power Management ICs, specifically for energy metering applications.
| Qty | Low | High |
|---|---|---|
| 1+ | $0.75 | $0.75 |
Estimated market price range - modelled values for guidance only, not live distributor offers.
The operating voltage range is 8.5 V to 21 V.
The breakdown voltage is 650V.
The maximum power output is 170W.
The switching frequency is 67kHz.
The operating temperature range is -25°C to 130°C (TJ).
The package is PG-TO220-6.
It is designed for through-hole mounting.
