The TDK Corporation HWS600-24/ME is an AC DC converter designed for ITE (Commercial) and Medical applications. This enclosed, conformal coated unit provides a single 24V output with a maximum current of 27A, delivering up to 600W of power.
Key electrical specifications include an input voltage range of 85 to 265 VAC and an efficiency of 85%. The converter offers features such as adjustable output, DC input capability, load sharing, and remote on/off functionality. It provides 3 kV of isolation voltage.
Mechanically, the HWS600-24/ME is designed for chassis mounting and has dimensions of 165.1mm x 100.1mm x 82.0mm (6.50" x 3.94" x 3.23"). The operating temperature range is -10°C to 70°C with derating. The unit is CE approved.
Environmental compliance includes RoHS3 compliance, an MSL rating of 1 Unlimited, and REACH unaffected status. The packaging is bulk.
The output voltage is 24V.
The maximum output current is 27A.
The power rating is 600W.
The input voltage range is 85 to 265 VAC.
The operating temperature range is -10°C to 70°C with derating.
It is a chassis mount type.
