The TDK Corporation HWS30A-24/ME is an AC/DC converter designed for various applications, including ITE (Commercial) and Medical equipment. This open frame unit is suitable for chassis mounting and operates with an input voltage range of 85 to 265V AC or 120 to 370V DC.
Key electrical specifications include a rated output voltage of 24V DC with an adjustable range of 19.2 to 28.8V DC. It can deliver a maximum output current of 1.3A, resulting in a maximum output power of 31.2W. The converter boasts a typical efficiency of 88% and features adjustable output, DC input capability, and universal input.
Mechanically, the HWS30A-24/ME has dimensions of 26.5mm in width, 82mm in height, and 95mm in depth, with a typical weight of 200g. It operates within a temperature range of -10 to 70°C and utilizes convection cooling. The unit is certified to safety standards including ES60601-1, EN60601-1, and CSA-C22.2 No.60101-1, and has an isolation voltage of 3 kV.
The input voltage range is 85 to 265VAC or 120 to 370VDC.
Rated output is 24V DC at 1.3A, adjustable from 19.2 to 28.8V.
The operating temperature range is -10 to 70°C with derating.
Typical efficiency is 88%.
Input-to-output isolation voltage is 3kV.
It is certified to ES60601-1, EN60601-1, and CSA-C22.2 No.60101-1 for medical and ITE applications.
