| Category | |
| Manufacturer Name | |
| Applications | |
| Approval Agency | |
| Current | |
| Efficiency | |
| Features | |
| Height | |
| Length | |
| Mounting Type | |
| Number of Outputs | |
| Operating Temperature | |
| Power (Watts) | |
| Type | |
| Voltage | |
| Width |
This TDK Corporation HWS300-15/HD is an AC/DC converter designed for ITE (Commercial) applications. It provides a power output of 300W with a current rating of 22A and an output voltage of 15V.
The converter features an enclosed, conformal coated type with chassis mounting. Key electrical specifications include 83% efficiency and a wide operating temperature range of -40°C to 71°C with derating. It also offers features such as adjustable output, DC input capability, load sharing, remote on/off, and remote sense.
Physical dimensions are 165.1mm in length, 61.0mm in width, and 82.0mm in height. The unit has an isolation voltage of 3kV and is CE approved. It is RoHS3 compliant and has an MSL rating of 1.
The output voltage is 15V DC and the output current is 22A.
The efficiency is 83%.
It is chassis mount.
The operating temperature range is -40°C to 71°C with derating.
Yes, it features adjustable output.
The isolation voltage is 3kV.
Yes, it is CE approved.
