The TDK Corporation HWS30-12/A is a 30W AC DC converter designed for industrial applications. It features a universal input voltage range of 85-265VAC and provides a stable 12V output at 2.5A.
This enclosed power supply offers key features such as adjustable output, DC input capability, and high efficiency of 83%. It is designed for chassis mounting and operates within a temperature range of -10°C to 70°C with derating. The unit meets various safety and compliance standards including CE, UL508, and SEMI F47.
With dimensions of 95.0mm x 26.4mm x 82.0mm, the HWS30-12/A is suitable for integration into various systems. Its robust design includes overcurrent and overvoltage protection, making it a reliable choice for ITE (Commercial) applications.
The output voltage is 12V.
The maximum output current is 2.5 A.
The power rating is 30W.
The operating temperature range is -10°C to 70°C (With Derating).
It supports a universal input voltage range of 85 - 265 VAC.
Yes, it is SEMI F47 Compliant for high line AC and complies with SEMI F47 for 200VAC line only.
It is certified by UL60950-1, CSA60950-1, EN60950-1, EN50178, UL508, and carries the CE Mark.
