HWB030S-12-R
Sanken
The Sanken HWB030S-12-R is a 30W open frame AC/DC converter with a 12V output, designed for chassis mounting. It operates from 85-264 VAC input and provides 3A of current.
| Category | |
| Manufacturer Name | |
| Applications | |
| Approval Agency | |
| Current | |
| Efficiency | |
| Features | |
| Mounting Type | |
| Number of Outputs | |
| Operating Temperature | |
| Power (Watts) | |
| Type | |
| Voltage |
The Sanken HWB030S-12 is an open frame AC DC converter designed for commercial ITE applications. It provides a power output of 30W and operates with a universal input voltage range from 85 to 264 VAC.
Key electrical specifications include a single output with a current rating of 3A and an efficiency of 77%. The converter is designed for chassis mounting and features like Load Sharing and Universal Input. Its operating temperature range is -10°C to 60°C.
This model is approved by CE, cURus, and GS agencies, indicating compliance with relevant safety standards. The dimensions are 136.0mm x 92.0mm x 34.0mm, making it suitable for integration into various systems where space is a consideration.
85 to 264 VAC.
Open frame, chassis mount.
-10°C to 60°C.
12V at 3A.
30W.
CE, cURus, GS.
77%.
