The Sanken HWB030S-05 is an open-frame AC/DC converter designed for ITE (Commercial) applications. It delivers a power output of 30W with a 6A current rating and a single output.
The converter operates with a universal input voltage range from 85 to 264 VAC, making it suitable for global use. Key electrical specifications include an efficiency of 75% and features like load sharing and universal input. The operating temperature range is -10°C to 60°C.
Mechanically, the HWB030S-05 is designed for chassis mounting and has dimensions of 136.0mm x 92.0mm x 34.0mm. It is certified by CE, cURus, and GS.
Environmental compliance includes RoHS3 compliance, Moisture Sensitivity Level 1, and REACH unaffected status.
The HWB030S-05 provides a single output of 5V at 6A.
The input voltage range is 85 to 264 VAC.
The operating temperature range is -10°C to 60°C.
The power rating is 30W.
It uses chassis mount packaging.
The dimensions are 136.0mm x 92.0mm x 34.0mm.
