HTSW-110-23-G-D Samtec HTSW-110-23-G-D is a 20 position, 2 row, 2.54mm pitch through hole header with gold plated phosphor bronze contacts.
Mfr Part #:

HTSW-110-23-G-D

Available from 1 distributors
Mfr Name: Samtec Inc.
Samtec Inc.
Samtec HTSW-110-23-G-D is a 20 position, 2 row, 2.54mm pitch through hole header with gold plated phosphor bronze contacts.
✓ Total Stock: 32 pcs
$ Price Range: $1.27 - $2.15

HTSW-110-23-G-D Available from 1 distributor

✓ Authorised
✓ Non-Authorised
Distributor Stock Pricing MOQ PKG Lead Time Date Code On Order Quantity On Order Delivery
Hybrid Electronics ✓
Non-Authorised Inventory information
32 pcs
On Request
32 pcs On Request 1 On Request On Request 1442 On Request On Request
DistyParts aggregates offers from multiple distributors. Final prices, lead times and terms are subject to the distributors' discretion and may change without prior notice. DistyParts is not liable for any discrepancies.

HTSW-110-23-G-D Specifications Quick View

Most important parameters for selection – full specs in datasheet.
Category
Manufacturer Name
Connector Type
Contact Finish
Contact Finish Thickness
Contact Length
Contact Material
Contact Shape
Contact Type
Current Rating (Amps)
Fastening Type
Insulation Color
Insulation Height
Insulation Material
Material Flammability Rating
Mounting Type
Number of Positions
Number of Positions Loaded
Number of Rows
Operating Temperature
Overall Contact Length
Pitch
Row Spacing
Shrouding
Style
Tape & Reel
Termination
View Similar Products (0)

HTSW-110-23-G-D Description

Short technical summary and product information.

The Samtec HTSW-110-23-G-D is a 20 position, 2 row unshrouded header with a 2.54mm pitch and row spacing. It features square male pins with gold plating over phosphor bronze contacts for reliable signal integrity. The insulator is molded from liquid crystal polymer (LCP) with a natural color and a UL94 V-0 flammability rating.



This through hole header supports solder termination and is designed for board-to-board or cable applications. The push-pull fastening type allows easy mating and unmating. The operating temperature range spans -55°C to 125°C, suitable for a wide variety of environments.



With an overall contact length of 11.30mm and an insulation height of 2.54mm, this connector offers a compact profile for dense PCB layouts. The gold contact finish provides corrosion resistance and durability for repeated mating cycles.

HTSW-110-23-G-D Quick Information

Product Type: Header
Series: HTSW
Canonical Name: Samtec HTSW-110-23-G-D 20 Position 2.54mm Pitch Through Hole Header
Subcategory: Unshrouded Header

HTSW-110-23-G-D Compliance

RoHS Status: RoHS Compliant
Moisture Sensitivity Level (MSL): 1 Unlimited
REACH Status: REACH Unaffected

HTSW-110-23-G-D Estimated Pricing

Qty Low High
1+ $2.15 $2.15
100+ $1.88 $1.88
500+ $1.63 $1.63
1,000+ $1.51 $1.51
2,000+ $1.39 $1.39
5,000+ $1.27 $1.27

Estimated market price range - modelled values for guidance only, not live distributor offers.

HTSW-110-23-G-D Features

  • 20 position 2.54mm pitch header.
  • Gold plated phosphor bronze contacts.
  • Through hole solder termination.
  • UL94 V-0 rated LCP insulator.
  • Operating temperature -55°C to 125°C.

HTSW-110-23-G-D Applications

  • Board-to-board interconnect applications.
  • Cable-to-board connection systems.
  • General purpose signal routing.

HTSW-110-23-G-D FAQs

6 frequently asked questions generated from this part’s specifications.
What is the pitch of the HTSW-110-23-G-D?

The pitch is 2.54mm (0.100").

How many positions does this header have?

It has 20 positions arranged in 2 rows.

What is the mounting type?

Through hole with solder termination.

What is the operating temperature range?

-55°C to 125°C.

What is the contact finish?

Gold plating with 0.25µm thickness.

Is the HTSW-110-23-G-D RoHS compliant?

It is listed as RoHS3 compliant (unverified).
