| Category | |
| Manufacturer Name | |
| Applications | |
| Approval Agency | |
| Current | |
| Dimensions | |
| Efficiency | |
| Features | |
| Height | |
| Input Voltage | |
| Length | |
| Mounting Type | |
| Number of Outputs | |
| Operating Temperature | |
| Overload Protection | |
| Power (Watts) | |
| Type | |
| Voltage | |
| Weight | |
| Width |
The Mean Well USA HRPG-150-15 is an enclosed AC/DC converter designed for ITE (Commercial) applications. It provides a 15V output voltage with a rated current of 10A, delivering a total power of 150W. The unit accepts a wide universal AC input range of 85-264VAC and also supports 120-370VDC input.
Key features include built-in active PFC, constant current limiting, and overload protection ranging from 105% to 135% of the rated load. It also offers over-voltage protection between 115% and 145% of the rated output. The DC voltage can be adjusted within ±15% of the rated output. The converter operates within a temperature range of -40°C to 70°C with derating.
With dimensions of 159.0mm x 97.0mm x 38.0mm (6.26" x 3.82" x 1.50"), it is suitable for chassis mounting. The HRPG-150-15 is built to withstand 300VAC surge input for 5 seconds and features a 3kVAC withstand voltage between input and output. It includes a 5V/0.3A standby output and is cooled by free air convection.
The HRPG-150-15 provides a 15V output at 10A rated current.
The input voltage range is 85 to 264 VAC or 120 to 370 VDC.
The operating temperature range is -40°C to 70°C with derating.
It includes overload protection at 105% to 135% and over voltage protection at 115% to 145% of rated output.
The typical efficiency is 87%.
The dimensions are 159.0 x 97.0 x 38.0 mm (6.25 x 3.81 x 1.49 in).
Yes, it includes a built-in 5V / 0.3A standby output.
