| Category | |
| Manufacturer Name | |
| Applications | |
| Approval Agency | |
| Current | |
| DC Voltage | |
| Efficiency | |
| Features | |
| Mounting Type | |
| No Load Power Consumption | |
| Number of Outputs | |
| Operating Temperature | |
| Power (Watts) | |
| Type | |
| Voltage | |
| Voltage Range |
The Mean Well HRP-150-5 is a high-reliability, enclosed AC/DC power supply designed for demanding applications. It delivers a 5V DC output with a rated current of 26A, providing a total power of 130W. This unit features a universal AC input range of 85-264VAC, making it suitable for global use.
Key electrical specifications include a typical efficiency of 85%, a power factor of 0.95, and a low no-load power consumption of less than 0.5W. The output voltage is adjustable between 4.3V and 5.8V with a tolerance of ±2.5%, and line and load regulation are both maintained at ±1.0%. It also includes features like adjustable output, PFC, remote sense, and protection against surges up to 300VAC for 5 seconds.
Designed for robust performance, the HRP-150-5 operates within a wide temperature range of -40°C to 70°C (with derating). Its mechanical dimensions are 159.0mm x 97.0mm x 38.0mm, and it is designed for chassis mounting. The enclosed form factor enhances safety and durability in industrial environments.
The HRP-150-5 has a nominal DC output voltage of 5V.
The HRP-150-5 has a rated current of 26A.
The HRP-150-5 provides a rated power of 130W.
The HRP-150-5 accepts a universal input voltage range of 85 to 264VAC.
The HRP-150-5 operates between -40°C and 70°C, with derating.
The HRP-150-5 measures 159.0mm in length, 97.0mm in width, and 38.0mm in height.
Yes, the HRP-150-5 can withstand a 300VAC surge for 5 seconds.
