| Distributor | Stock | Pricing | MOQ | PKG | Lead Time | Date Code | On Order Quantity | On Order Delivery | |
|---|---|---|---|---|---|---|---|---|---|
|
20 pcs
|
20 pcs | On Request | 1 | On Request | On Request | On Request | On Request | On Request |
| Category | |
| Manufacturer Name | |
| Cable Opening | |
| Color | |
| Connector Type | |
| Contact Finish | |
| Current Rating (Amps) | |
| Fastening Type | |
| Features | |
| Ingress Protection | |
| Material Flammability Rating | |
| Mounting Type | |
| Number of Positions | |
| Operating Temperature | |
| Orientation | |
| Primary Material | |
| Shell Material | |
| Shell Size | |
| Shielding | |
| Tape & Reel | |
| Termination | |
| Termination Style | |
| Voltage Rating | |
| Voltage Rating DC |
The HR30-6P-6S(31) is a circular connector plug from Hirose Electric's HR30 series. It features 6 power contacts (female sockets) arranged in a keyed orientation to prevent misalignment. The connector uses a push-pull fastening mechanism for secure mating and includes a backshell, coupling nut, and strain relief for cable management. Termination is via solder cup, suitable for field-installable wiring. The shell is made of Polybutylene Terephthalate (PBT) with a black color, and contacts are gold-plated for reliable conductivity. The connector is rated for a current of 2A per contact and can withstand 100VAC or 140VDC. It is designed for free hanging (in-line) mounting and offers IP67 and IP68 protection against dust and water immersion, making it suitable for outdoor or harsh environments. The operating temperature range is -25°C to 85°C, and the material flammability rating is UL94 V-0. The cable opening accommodates diameters from 4.20mm to 5.00mm. This connector is unshielded.
| Qty | Low | High |
|---|---|---|
| 1+ | $12.95 | $12.95 |
| 10+ | $11.01 | $11.01 |
| 25+ | $10.32 | $10.32 |
| 50+ | $9.82 | $9.82 |
| 100+ | $9.35 | $9.35 |
| 250+ | $8.76 | $8.76 |
| 500+ | $8.70 | $8.70 |
Estimated market price range - modelled values for guidance only, not live distributor offers.
6 positions, all power contacts.
2A per contact.
100VAC or 140VDC.
Free hanging (in-line).
IP67 and IP68, dust tight and waterproof.
-25°C to 85°C.
Polybutylene Terephthalate (PBT).
