| Category | |
| Manufacturer Name | |
| Applications | |
| Approval Agency | |
| Class | |
| Current | |
| Efficiency | |
| Height | |
| Input Voltage | |
| Length | |
| Mounting Type | |
| Number of Outputs | |
| Operating Temperature | |
| Output Current | |
| Output Voltage | |
| Power | |
| Power (Watts) | |
| Type | |
| Voltage | |
| Width |
The Bel Power Solutions HP4320-9RG is a high-performance DC-DC converter designed for demanding applications. It offers a robust 192W power output and features a wide input voltage range from 16.8 to 137.5 VDC, ensuring flexibility in various power systems.
This converter provides four independent, isolated 12V outputs, each capable of delivering 4A. It incorporates essential features such as output voltage adjustment, over-temperature protection, and low inrush current. The unit is built to withstand harsh environments, with conformal coating on PCBs and a fully enclosed chassis mount design.
Compliance with safety standards like IEC/EN 62368-1 and UL/CSA 62368-1, along with EMC standards such as EN 50155 and EN 50121-3-2, makes the HP4320-9RG suitable for industrial, railway, and ITE applications. Its operating temperature range of -40°C to +71°C further enhances its suitability for rugged environments.
| Qty | Low | High |
|---|---|---|
| 1+ | $635.00 | $635.00 |
Estimated market price range - modelled values for guidance only, not live distributor offers.
The input voltage range is 16.8 to 137.5 VDC.
It has 4 independent, isolated outputs.
Each of the 4 outputs provides 12 VDC at 4 A.
The operating temperature range is -40°C to +71°C.
Yes, it is RoHS3 Compliant.
