Mfr Part #:

HN15-4.5-A+G

Mfr Name: SL Power Electronics Manufacture of Condor/Ault Brands

The SL Power Electronics HN15-4.5-A+G is a linear AC DC converter providing a 15V output at 4.5A, delivering 68W of power. It features a universal input and chassis mount.

Stock on Request

HN15-4.5-A+G Description

Short technical summary and product information.

The HN15-4.5-A+G from SL Power Electronics is a linear AC DC converter designed for ITE (Commercial) applications. It offers a single 15V output with a current rating of 4.5A, resulting in a total power output of 68W.

This converter operates with a universal input voltage range of 100 to 240 VAC and features an efficiency of 55%. Key features include adjustable output, remote sense capability, and automatic current limit/foldback for short circuit protection. The operating temperature range is 0°C to 70°C with derating.

Designed for chassis mounting, the unit measures 177.8mm x 124.0mm x 69.9mm. It is approved by CE, cURus, and TUV, and is RoHS3 compliant. The datasheet indicates a high MTBF of over 200,000 hours.

HN15-4.5-A+G Quick Information

Product Type: AC DC Converter

Series: Linear N

Canonical Name: SL Power Electronics Manufacture of Condor/Ault Brands HN15-4.5-A+G Linear AC DC Converter

Subcategory: AC DC Converter

HN15-4.5-A+G Compliance

RoHS Status: RoHS Compliant

Moisture Sensitivity Level (MSL): 1 Unlimited

REACH Status: REACH Unaffected

HN15-4.5-A+G Features

Linear AC DC converter with 15V output.
Rated for 4.5A current and 68W power.
Universal input voltage range (100-240 VAC).
Chassis mountable for easy integration.
Features remote sense and adjustable output.

HN15-4.5-A+G Applications

Linear AC-DC conversion for commercial ITE equipment
15V 4.5A output for industrial control systems
68W power supply for test and measurement devices
Chassis-mount power for benchtop instrumentation
Universal input supply for global commercial applications

HN15-4.5-A+G FAQs

7 frequently asked questions generated from this part’s specifications.

What is the output voltage of the HN15-4.5-A+G?

The output voltage is 15V.

What is the maximum output current for the HN15-4.5-A+G?

The maximum output current is 4.5A.

What is the power rating of the HN15-4.5-A+G?

The power rating is 68W.

What is the input voltage range for this AC DC converter?

The input voltage range is 100 to 240 VAC.

What is the operating temperature range?

The operating temperature range is 0°C to 70°C with derating.

Does the HN15-4.5-A+G have remote sense capability?

Yes, it provides remote sensing.

What are the dimensions of the HN15-4.5-A+G?

The dimensions are 7.00" L x 4.88" W x 2.75" H (177.8mm x 124.0mm x 69.9mm).

Category	AC DC Converters
Manufacturer Name	SL Power Electronics Manufacture of Condor/Ault Brands
Applications	ITE (Commercial)
Approval Agency	CE \| cURus \| TUV
Current	4.5 A
Dimensions	7.00" L x 4.88" W x 2.75" H (177.8mm x 124.0mm x 69.9mm)
Efficiency	55%
Features	Adjustable Output \| Remote Sense \| Universal Input
Height	69.9mm (2.75")
Input Voltage	100 ~ 240 VAC
Length	177.8mm (7.00")
Mounting Type	Chassis Mount
Number of Outputs	1
Operating Temperature	0°C ~ 70°C (With Derating)
Output Current	4.5 A
Output Voltage	15V
Power (Watts)	68W
Storage Temperature	-40 to +85 °C
Temperature Coefficient	±0.01%/°C
Type	Linear
Voltage	100 ~ 240 VAC
Width	124.0mm (4.88")
