Mfr Part #:

HMC341LC3B

Mfr Name: AD

The Analog Devices HMC341LC3B is a wide band, low power RF amplifier operating from 21 GHz to 29 GHz. It features a typical gain of 13 dB and a noise figure of 3 dB.

✓ Total Stock: 8,947 pcs

$ Price Range: $5.77

HMC341LC3B Available from 2 distributors

✓ Authorised

✓ Non-Authorised

Distributor		Stock	Pricing	MOQ	PKG	Lead Time	Date Code	On Order Quantity	On Order Delivery
Optech Co.,Limited ✓ Non-Authorised Inventory information	8,747 pcs On Request	8747 pcs	On Request	1	On Request	On Request	1651+	On Request	On Request
Smaxon Electronics ✓ Non-Authorised Inventory information	200 pcs On Request	200 pcs	On Request	1	On Request	On Request	20+	On Request	On Request

HMC341LC3B Specifications Quick View

Most important parameters for selection – full specs in datasheet.

SELECT ALL

Category	New Products
Manufacturer Name	AD
Frequency	21 GHz - 29 GHz
Mounting Type	Surface Mount
Noise Figure	3 dB
Operating Temperature	-40 °C Cel / 85 °C Cel
Supplier Device Package	12-SMT (3x3)
Voltage Supply	3 V

View Similar Products (0)

HMC341LC3B Description

Short technical summary and product information.

The HMC341LC3B from Analog Devices is a GaAs MMIC Low Noise Amplifier (LNA) designed for wide band, low power RF applications. It operates across a frequency range of 21 GHz to 29 GHz, making it suitable for various high-frequency systems.

Key electrical characteristics include a typical gain of 13 dB and a noise figure of 3 dB, ensuring efficient signal amplification with minimal added noise. The amplifier has a P1dB of 8.5 dBm and requires a supply voltage of 3V, drawing a typical current of 35mA. Its characteristic impedance is 50 ohms.

Packaged in a 12-SMT (3x3) configuration, the HMC341LC3B is designed for surface mount assembly. The operating temperature range is from -40°C to 85°C. This component is lead-free and compliant with EU RoHS standards.

HMC341LC3B Quick Information

Product Type: RF Amplifier

Series: -

Canonical Name: HMC341LC3B RF/Microwave Wide Band Low Power Amplifier

Subcategory: Low Noise Amplifier

HMC341LC3B Compliance

RoHS Status: RoHS Compliant

Moisture Sensitivity Level (MSL): 1 Unlimited

REACH Status: REACH Unaffected

Lead Free: Yes

HMC341LC3B Estimated Pricing

Qty	Low	High
1+	$5.77	$5.77

Estimated market price range - modelled values for guidance only, not live distributor offers.

HMC341LC3B Features

Wide band low power RF amplifier.
Operates from 21 GHz to 29 GHz.
Features 13 dB typical gain.
Low noise figure of 3 dB.
Surface mount 12-SMT (3x3) package.

HMC341LC3B Applications

Suitable for high-frequency systems.
Ideal for RF signal amplification.
Used in wireless communication.
Designed for low power applications.

HMC341LC3B FAQs

7 frequently asked questions generated from this part’s specifications.

What is the operating frequency range of the HMC341LC3B?

The HMC341LC3B operates from 21 GHz to 29 GHz.

What is the typical gain of the HMC341LC3B amplifier?

The typical gain is 13 dB over a 24GHz ~ 26GHz test frequency.

What is the noise figure for the HMC341LC3B?

The noise figure is 3 dB.

What is the supply voltage for the HMC341LC3B?

The typical supply voltage is 3V.

What is the operating temperature range for this component?

The operating temperature range is -40°C to 85°C.

What type of package is the HMC341LC3B in?

It is supplied in a 12-SMT (3x3) package, with a package/case of 12-VFQFN Exposed Pad.

Is the HMC341LC3B lead-free and RoHS compliant?

Yes, the HMC341LC3B is lead-free and EU RoHS compliant.
