| Distributor | Stock | Pricing | MOQ | PKG | Lead Time | Date Code | On Order Quantity | On Order Delivery | |
|---|---|---|---|---|---|---|---|---|---|
|
6,457 pcs
|
6457 pcs | On Request | 1 | On Request | On Request | On Request | On Request | On Request |
| Category | |
| Manufacturer Name | |
| Insertion Loss | |
| Lead Style | |
| Mounting Style | |
| Power Dissipation | |
| SVHC Present | |
| Technology |
The HMC1055 is a single pole, single throw (SPST) RF switch integrated circuit manufactured by Hittite Microwave. It is designed for applications operating across a frequency range of DC to 4 GHz. This GaAs technology device offers a typical insertion loss of 1.8 dB and an off-isolation of 28 dB.
The HMC1055 operates with a supply voltage between 1.2V and 5V, with a maximum power dissipation of 0.88W. It is specified for an operating temperature range of -40°C to +85°C. The component is housed in a DFN-8 package and is suitable for surface mount (SMD/SMT) applications, supplied on a reel.
This RF switch IC is well-suited for various RF signal routing and switching tasks in communication systems, test equipment, and other electronic designs requiring reliable RF signal management.
| Qty | Low | High |
|---|---|---|
| 1+ | $0.99 | $0.99 |
Estimated market price range - modelled values for guidance only, not live distributor offers.
The HMC1055 operates from DC to 4 GHz.
The typical insertion loss is 1.8 dB.
The typical off isolation is 28 dB.
The supply voltage ranges from 1.2 V to 5 V.
The HMC1055 operates between -40 °C and 85 °C.
The HMC1055 is in a DFN-8 package.
The HMC1055 is a surface mount (SMD/SMT) device.
