| Distributor | Stock | Pricing | MOQ | PKG | Lead Time | Date Code | On Order Quantity | On Order Delivery | |
|---|---|---|---|---|---|---|---|---|---|
|
100 pcs
|
100 pcs | On Request | 1 | On Request | On Request | On Request | On Request | On Request |
| Category | |
| Manufacturer Name | |
| Forward Voltage | |
| Height | |
| Millicandela Rating | |
| Mounting Type | |
| Supplier Device Package | |
| Viewing Angle |
The Avago Technologies HLMP1503 is a red light-emitting diode designed for various electronic applications. It operates with a typical forward voltage of 1.8V and provides a luminous intensity of 45mcd at a test current of 20mA.
This LED has a wide viewing angle of 60°, making it suitable for indicator applications where broad visibility is required. The peak wavelength of the emitted light is 660nm.
Designed for through-hole mounting, the HLMP1503 comes in a T-1 radial package. Its maximum height is 6.30mm, facilitating integration into various circuit designs. The component is specified with RoHS3 compliance and MSL 1 rating.
| Qty | Low | High |
|---|---|---|
| 1+ | $0.17 | $0.17 |
Estimated market price range - modelled values for guidance only, not live distributor offers.
The typical forward voltage for the HLMP1503 LED is 1.8V.
The luminous intensity of the HLMP1503 LED is 45mcd at a test current of 20mA.
The viewing angle of the HLMP1503 LED is 60°.
The peak wavelength of the HLMP1503 LED is 660nm.
The HLMP1503 LED is mounted using the through-hole method.
The HLMP1503 LED is RoHS3 Compliant.
The Moisture Sensitivity Level (MSL) for the HLMP1503 LED is 1 Unlimited.
