| Distributor | Stock | Pricing | MOQ | PKG | Lead Time | Date Code | On Order Quantity | On Order Delivery | |
|---|---|---|---|---|---|---|---|---|---|
|
108 pcs
|
108 pcs | On Request | 1 | On Request | On Request | On Request | On Request | On Request |
| Category | |
| Manufacturer Name | |
| Approval Agency | |
| Current | |
| Efficiency | |
| Features | |
| Height | |
| Length | |
| Number of Outputs | |
| Operating Temperature | |
| Power (Watts) | |
| Ratings | |
| Termination Style | |
| Topology | |
| Type | |
| Voltage | |
| Width |
The Mean Well USA HLG-240H-12 is a 192W AC-DC LED driver designed for constant current and constant voltage operation. It delivers a single output of 12V at 16A with a high efficiency of 90%. The driver features an IP67 rating for dust and water ingress protection, making it suitable for outdoor and harsh environment applications.
This LED driver accepts a nominal AC input of 90VAC and employs an AC-DC converter topology. It includes comprehensive protection features: overcurrent protection (OCP), overtemperature protection (OTP), overvoltage protection (OVP), and short circuit protection (SCP). The operating temperature range spans from -40°C to 90°C.
The HLG-240H-12 is terminated with wire leads for easy installation. Its compact metal case measures 220.2mm x 68.0mm x 38.8mm (8.67" x 2.68" x 1.53"). The driver carries multiple safety approvals including CB, CCC, CE, cURus, PSE, RCM, and TUV.
| Qty | Low | High |
|---|---|---|
| 1+ | $73.30 | $73.30 |
| 5+ | $69.90 | $69.90 |
| 12+ | $66.80 | $66.80 |
| 24+ | $64.80 | $64.80 |
Estimated market price range - modelled values for guidance only, not live distributor offers.
The operating temperature range is -40°C to 90°C.
The output is 12V at 16A, providing 192W of power.
The RoHS status is listed as RoHS3 Compliant, but this is unverified.
It includes overcurrent (OCP), overtemperature (OTP), overvoltage (OVP), and short circuit (SCP) protection.
The IP rating is IP67.
