| Distributor | Stock | Pricing | MOQ | PKG | Lead Time | Date Code | On Order Quantity | On Order Delivery | |
|---|---|---|---|---|---|---|---|---|---|
|
53 pcs
|
53 pcs | On Request | 1 | On Request | On Request | On Request | On Request | On Request |
| Category | |
| Manufacturer Name | |
| Approval Agency | |
| Current | |
| Efficiency | |
| Features | |
| Height | |
| Industrial Grade | |
| Lead Style | |
| Length | |
| Number of Outputs | |
| Operating Temperature | |
| Power (Watts) | |
| Ratings | |
| Tape & Reel | |
| Termination Style | |
| Topology | |
| Type | |
| Voltage | |
| Width |
The HLG-150H-12A is a 150W AC-DC LED driver from Mean Well USA, designed for constant current and constant voltage operation. It delivers a rated output current of 12.5A with an output voltage range of 10.8-13.5V. The driver achieves an efficiency of 91.5%, reducing power loss and heat generation.
Built for reliability, the HLG-150H-12A includes comprehensive protection features: over current (OCP), over temperature (OTP), over voltage (OVP), and short circuit (SCP). Its IP65 ingress protection rating makes it suitable for outdoor and damp environments. The driver operates over a wide temperature range of -40°C to 90°C.
The unit features wire leads for termination and measures 204.0mm x 68.0mm x 38.8mm (8.03" x 2.68" x 1.53"). It accepts an input voltage of 90VAC. The topology is an AC DC converter, making it suitable for direct connection to mains power.
| Qty | Low | High |
|---|---|---|
| 1+ | $55.30 | $55.30 |
| 5+ | $52.70 | $52.70 |
| 12+ | $50.30 | $50.30 |
| 24+ | $48.90 | $48.90 |
Estimated market price range - modelled values for guidance only, not live distributor offers.
-40°C to 90°C
Yes, it is listed as RoHS3 Compliant.
90VAC
OCP, OTP, OVP, SCP
91.5%
IP65
12.5A
