| Distributor | Stock | Pricing | MOQ | PKG | Lead Time | Date Code | On Order Quantity | On Order Delivery | |
|---|---|---|---|---|---|---|---|---|---|
|
95 pcs
|
95 pcs | On Request | 1 | On Request | On Request | On Request | On Request | On Request |
| Category | |
| Manufacturer Name | |
| Cable End Type | |
| Connector | |
| Contact Finish | |
| Contact Material | |
| FFC, FCB Thickness | |
| Flat Flex Type | |
| Height Above Board | |
| Housing Material | |
| Lead Spacing | |
| Lead Style | |
| Material Flammability Rating | |
| Mounting Type | |
| Number of Positions | |
| Operating Temperature | |
| Pitch | |
| SVHC Present | |
| Tape & Reel | |
| Termination | |
| Termination Style | |
| Voltage Rating |
The Amphenol ICC HFW5R-1STE1LF is a 5-position, 1.00mm pitch FFC/FPC connector designed for surface mount right angle mounting. It features bottom contacts and tin-plated phosphor bronze contacts for reliable signal transmission. The housing is molded from glass-filled polyamide (PA6T/Nylon 6T) with a UL94 V-0 flammability rating, ensuring robust mechanical support and fire safety. It accepts 0.30mm thick FFC or FPC cables with either straight or tapered ends, offering design flexibility. The connector measures 1.90mm in height above the board, making it suitable for compact, low-profile designs. With an operating temperature range of -55°C to 105°C and a voltage rating of 100V, it can withstand demanding environmental conditions. The right angle orientation allows for space-efficient cable routing on the PCB.
| Qty | Low | High |
|---|---|---|
| 4,000+ | $0.13 | $0.13 |
Estimated market price range - modelled values for guidance only, not live distributor offers.
This connector has 5 positions.
The pitch is 1.00mm.
It is surface mount, right angle.
The voltage rating is 100V.
It accepts FFC and FPC cables with a thickness of 0.30mm, and either straight or tapered ends.
The operating temperature range is -55°C to 105°C.
The housing is glass-filled polyamide (PA6T/Nylon 6T) with a UL94 V-0 flammability rating.
