The TDK Corporation HFE1600-LAN is a dedicated LAN module accessory for the HFE1600 Series of AC-DC industrial power supplies. This module enables communication capabilities for the HFE1600 power supplies, facilitating remote monitoring and control.
The HFE1600 Series power supplies are designed for high-density applications, capable of providing up to 7,600W of bulk power when configured in a 1U rack. They feature internal ORing MOSFETs and current share for automatic parallel operation, making them suitable for N+1 redundancy configurations. The power supplies support an optional isolated PMBus™ (I2C) interface or a plug-in LAN module like the HFE1600-LAN.
Key electrical specifications for the HFE1600 Series include an input voltage range of 85-265 Vac and an input frequency of 47-63 Hz. They offer high efficiency, with values reaching up to 92% depending on the model. The series also complies with various industry standards for EMI and safety, including EN55022, FCC Part 15, and IEC/UL/CSA/EN62368-1.
The HFE1600-LAN module itself integrates seamlessly into the HFE1600 power supply system, expanding its functionality without requiring significant additional space. This allows for easy integration of advanced communication protocols into industrial power solutions.
The input voltage range is 85 - 265 Vac.
The input frequency range is 47 - 63 Hz.
The maximum input current is 12.4 / 8.1 A at 115/230Vac.
The hold-up time is greater than 10ms at 100/230Vac input and 80% loading.
The HFE1600 Series complies with IEC/UL/CSA/EN62368-1.
The RoHS status is RoHS3 Compliant.
The Moisture Sensitivity Level is 1 Unlimited.
