Mfr Part #:

HFBR-59L1AL

The Agilent Technologies HFBR-59L1AL is an optical transceiver designed for serial data communications. It supports data rates up to 1.25 Gbps over multimode fiber.

✓ Total Stock: 4 pcs

$ Price Range: $0.99

HFBR-59L1AL Available from 1 distributor

✓ Authorised

✓ Non-Authorised

Distributor		Stock	Pricing	MOQ	PKG	Lead Time	Date Code	On Order Quantity	On Order Delivery
Bristol Electronics ✓ Non-Authorised Inventory information	4 pcs On Request	4 pcs	On Request	1	On Request	On Request	On Request	On Request	On Request

HFBR-59L1AL Specifications Quick View

Most important parameters for selection – full specs in datasheet.

SELECT ALL

Category	New Products
Manufacturer Name	Agilent Technologies
Mounting Type	Through Hole
Operating Temperature	-10 to 85°C
Operating Voltage	3.3 VDC
Wavelength	850 nm

View Similar Products (0)

HFBR-59L1AL Description

Short technical summary and product information.

The HFBR-59L1AL from Agilent Technologies is a high-performance, cost-effective optical transceiver for serial optical data communications applications. It operates at data rates of 1.25 Gbps for Gigabit Ethernet (1000BASE-SX) and 1.0625 Gbps for Fibre Channel.

This module is designed for multimode fiber and operates at a nominal wavelength of 850 nm, utilizing a Vertical Cavity Surface Emitting Laser (VCSEL) transmitter. It features a 3.3 VDC compatible technology and is compliant with the Small Form Factor Multi-Source Agreement (SFF-MSA).

The transceiver supports link lengths up to 500 meters over 50/125 µm multimode fiber at 1.25 Gbps and up to 300 meters over 62.5/125 µm multimode fiber at 1.0625 Gbps. It is designed for a wide voltage and temperature range, operating from -10 to 85°C. The HFBR-59L1AL uses an industry-standard 2x5 SFF package with an LC-duplex connector for the optical interface.

Applications include short reach Gigabit Ethernet links, high-speed backplane interconnects, switched backbones, iSCSI applications, mass storage system I/O, computer system I/O, high-speed peripheral interfaces, high-speed switching systems, and host adaptor I/O.

HFBR-59L1AL Quick Information

Product Type: Optical Transceiver

Series: HFBR-59L1AL

Canonical Name: HFBR-59L1AL Optical Transceiver

Subcategory: Optical Transceiver

HFBR-59L1AL Compliance

RoHS Status: RoHS Compliant

Moisture Sensitivity Level (MSL): 1 Unlimited

REACH Status: REACH Unaffected

HFBR-59L1AL Estimated Pricing

Qty	Low	High
1+	$0.99	$0.99

Estimated market price range - modelled values for guidance only, not live distributor offers.

HFBR-59L1AL Features

Supports 1.25 Gbps Gigabit Ethernet.
Supports 1.0625 Gbps Fibre Channel.
Operates at 850 nm wavelength.
Up to 500m link length on MMF.
Single 3.3 VDC power supply.

HFBR-59L1AL Applications

Short reach Gigabit Ethernet links.
High-speed backplane interconnects.
Switched backbones.
iSCSI applications.
Mass storage system I/O.

HFBR-59L1AL FAQs

7 frequently asked questions generated from this part’s specifications.

What data rates does the HFBR-59L1AL support?

The HFBR-59L1AL supports 1.25 GBd for IEEE 802.3 Gigabit Ethernet 1000BASE-SX and 1.0625 GBd for Fibre Channel FC-PI 100-M5-SN-I and FC-PI 100-M6-SN-I.

What is the operating wavelength of the HFBR-59L1AL?

The nominal operating wavelength is 850 nm.

What is the operating voltage of the HFBR-59L1AL?

The module operates from a single +3.3 VDC power supply.

What is the operating temperature range of the HFBR-59L1AL?

The operating temperature range is -10 to 85°C.

What connector type does the HFBR-59L1AL use?

The module uses an LC duplex connector optical interface.

What is the form factor of the HFBR-59L1AL?

The module is in a 2x5 form factor with through-hole mounting.

What is the laser safety class of the HFBR-59L1AL?

The laser is Class I (eye safe) per US 21 CFR (J) and EN 60825-1.
