| Category | |
| Manufacturer Name | |
| Accessory Type | |
| Insulation | |
| Material | |
| Mounting Type | |
| Number of Poles | |
| Switching Cycles | |
| Voltage Rating |
This Siemens HF323JCH is a heavy duty safety switch from the VBII series, suitable for protecting portable equipment in industrial settings. It is rated for 240V and 100A, with 3 poles.
The switch features a durable steel construction with a Type 12 enclosure, providing protection against dust and water ingress. It is designed for surface mounting and accepts Crouse-Hinds Arktite plugs, utilizing an interlocked plug connection type.
With a mechanical service life of 10,000 switching cycles, this safety switch is built for reliability. It operates within an ambient temperature range of -29°C to 85°C. The switch is certified to UL98 standards, ensuring compliance with safety regulations.
The Siemens HF323JCH safety switch has a voltage rating of 240V.
The ampacity of the HF323JCH switch is 100A.
The Siemens HF323JCH has 3 poles.
The operating temperature range for the HF323JCH is -29°C to 85°C.
The HF323JCH features a Type 12 enclosure.
The mechanical service life of the HF323JCH is 10,000 switching cycles.
The RoHS status is RoHS3 Compliant.
