| Distributor | Stock | Pricing | MOQ | PKG | Lead Time | Date Code | On Order Quantity | On Order Delivery | |
|---|---|---|---|---|---|---|---|---|---|
|
468 pcs
|
468 pcs | On Request | 1 | On Request | On Request | On Request | On Request | On Request |
| Category | |
| Manufacturer Name | |
| Coil Resistance | |
| Coil Voltage | |
| Depth | |
| Height | |
| Length | |
| Mounting Type | |
| Number of Poles | |
| SVHC Present | |
| Standards | |
| Terminal Type |
The Hongfa HF115F/024-1ZS1AF is a single pole double throw (SPDT) relay designed for PCB mounting. It operates with a 24VDC coil and offers a significant switching current capability of 16A.
This relay features a low profile design with a maximum height of 15.7mm, making it suitable for space-constrained applications. It has a maximum switching voltage of 440VAC and 300VDC, with a maximum AC switching power of 4 kVA. The isolation between coil and contacts is rated at 5kVAC.
Constructed with AgSnO2 contacts for enhanced switching performance, this relay is fully sealed as standard. It conforms to various standards including IEC 60335-1 and VDE 0435/0631/0700, and holds approvals from UL, CQC, and VDE.
Key specifications include a coil power of 400mW, coil resistance of 1.44 kΩ, and dimensions of 29mm length, 12.7mm depth, and 15.7mm height. The terminal type is through hole, and the pinning is 3.5mm.
| Qty | Low | High |
|---|---|---|
| 1+ | $2.00 | $2.00 |
Estimated market price range - modelled values for guidance only, not live distributor offers.
The coil voltage is 24 VDC.
The maximum switching current is 16A.
The maximum AC switching voltage is 440 VAC.
It has an SPDT (Single Pole Double Throw) contact configuration.
This relay is designed for PCB Mount.
The coil power is 400mW.
The relay has a length of 29mm, a depth of 12.7mm, and a height of 15.7mm.
