| Distributor | Stock | Pricing | MOQ | PKG | Lead Time | Date Code | On Order Quantity | On Order Delivery | |
|---|---|---|---|---|---|---|---|---|---|
|
18,500 pcs
|
18500 pcs | On Request | 1 | On Request | On Request | On Request | On Request | On Request |
| Category | |
| Manufacturer Name | |
| Forward Voltage | |
| Junction Capacitance | |
| Mounting Type | |
| Operating Temperature Range | |
| Reverse Recovery Time | |
| Weight |
The HER308 is a 3.0A high efficiency rectifier diode manufactured by Micron Technology. It features a diffused junction, low forward voltage drop, and high surge current capability, making it suitable for various power supply and rectification applications.
Key electrical characteristics include a maximum average rectified output current of 3.0A at 55°C ambient temperature and a peak repetitive reverse voltage of up to 1000V. The forward voltage drop is a maximum of 1.7V at 3.0A, and the reverse recovery time is typically 75ns. The operating junction temperature range is -65°C to +125°C.
Mechanically, the HER308 is housed in a molded plastic case (DO-201AD) with plated leads that are solderable per MIL-STD-202, Method 208. The approximate weight is 1.2 grams. Mounting can be in any position.
This rectifier is designed for single-phase, half-wave applications with resistive or inductive loads. For capacitive loads, the current should be derated by 20%. The epoxy used is UL 94V-O rate flame retardant.
| Qty | Low | High |
|---|---|---|
| 1+ | $0.99 | $0.99 |
Estimated market price range - modelled values for guidance only, not live distributor offers.
The HER308 has a peak repetitive reverse voltage rating of 1000V.
The HER308 has an average rectified output current of 3.0A at 55°C.
The maximum forward voltage drop for the HER308 at 3.0A is 1.7V.
The typical reverse recovery time for the HER308 is 75ns.
The HER308 operates between -65°C and +125°C.
The HER308 is available in a DO-201AD package.
