| Category | |
| Manufacturer Name | |
| Applications | |
| Approval Agency | |
| Current | |
| Efficiency | |
| Features | |
| Height | |
| Input Voltage | |
| Length | |
| Mounting Type | |
| Number of Outputs | |
| Operating Temperature | |
| Overload Protection | |
| Power (Watts) | |
| Storage Temperature | |
| Tape & Reel | |
| Temperature Coefficient | |
| Type | |
| Voltage | |
| Width |
The Mean Well HDP-240 is a versatile enclosed AC/DC power supply designed for ITE (Commercial) applications. It provides dual outputs with voltages of 3.8V and 2.8V, delivering a combined power of up to 228W. The unit accepts a universal AC input range of 90-264VAC and features a built-in active Power Factor Correction (PFC) function, contributing to its high efficiency of up to 84%.
Key protections include short circuit, overload, over voltage, and over temperature, ensuring reliable operation. The HDP-240 is designed with a 1U low profile of 36mm and chassis mounting. It also incorporates ZVS technology to reduce power dissipation and includes an LED indicator for power status. The power supply operates within a wide temperature range of -30°C to 70°C and comes with a 3-year warranty.
The HDP-240 provides dual outputs: 3.8V and 2.8V.
The HDP-240 has a rated current of 41.5A for the 3.8V output and 25A for the 2.8V output.
The HDP-240 has a typical power rating of 227.7W and a maximum power rating of 241W.
The HDP-240 has a typical efficiency of 84% at full load.
The HDP-240 operates within a temperature range of -30°C to 70°C.
The HDP-240 complies with UL 62368-1, IEC/EN 62368-1, and EAC TP TC 004.
The HDP-240 features hiccup mode overload protection that recovers automatically after the fault condition is removed.
