| Category | |
| Manufacturer Name | |
| Applications | |
| Approval Agency | |
| Current | |
| Efficiency | |
| Features | |
| Height | |
| Length | |
| Mounting Type | |
| Number of Outputs | |
| Operating Temperature | |
| Power (Watts) | |
| Stability | |
| Storage Temperature | |
| Temperature Coefficient | |
| Type | |
| Voltage | |
| Width |
This SL Power Electronics HDCC150W-A+G is a linear AC/DC converter designed for ITE (Commercial) applications. It offers multiple output voltages including 5V, -12V, and an adjustable output, providing a total power of 142W.
The unit is chassis mountable and features adjustable output, remote sense, and universal input capabilities. It operates within a temperature range of 0°C to 70°C with derating and includes automatic current limit/foldback for short circuit protection.
Key electrical specifications include line regulation of ±0.05% for a 10% change and load regulation of ±0.05% for a 50% load change. The output ripple is a maximum of 3 mV +0.05% of output voltage, peak to peak. Transient response is less than 50 microseconds for a 50% load change.
Compliance certifications include CE, cURus, and TUV. The device also meets FCC and CISPR22 Class B conducted emissions standards. It is RoHS3 Compliant, has an MSL of 1 Unlimited, and is REACH Unaffected.
