HD64F2319EVTE25 The Renesas HD64F2319EVTE25 is a 16-bit microcontroller from the H8S/2300 family. It operates at 25MHz and offers 512KB of Flash memory and 8KB of RAM.
Mfr Part #:

HD64F2319EVTE25

Available from 1 distributors
Mfr Name: Renesas
Renesas
The Renesas HD64F2319EVTE25 is a 16-bit microcontroller from the H8S/2300 family. It operates at 25MHz and offers 512KB of Flash memory and 8KB of RAM.
✓ Total Stock: 2,583 pcs
$ Price Range: $2.50

HD64F2319EVTE25 Available from 1 distributor

✓ Authorised
✓ Non-Authorised
Distributor Stock Pricing MOQ PKG Lead Time Date Code On Order Quantity On Order Delivery
Romaks Technologies ✓
Non-Authorised Inventory information
2,583 pcs
On Request
2583 pcs On Request 1 On Request On Request On Request On Request On Request
DistyParts aggregates offers from multiple distributors. Final prices, lead times and terms are subject to the distributors' discretion and may change without prior notice. DistyParts is not liable for any discrepancies.

HD64F2319EVTE25 Specifications Quick View

Most important parameters for selection – full specs in datasheet.
Category
Manufacturer Name
Core Processor
Core Size
Frequency
Mounting Type
Operating Temperature
Operating Voltage
Peripherals
RAM Size
SVHC Present
Supplier Package
View Similar Products (0)

HD64F2319EVTE25 Description

Short technical summary and product information.

The Renesas HD64F2319EVTE25 is a 16-bit microcontroller designed for embedded applications. It is part of the H8S/2300 series and features a core clock speed of 25MHz.



This microcontroller offers 512KB of Flash memory for program storage and 8KB of RAM for data manipulation. It includes various peripherals such as SCI, Clock, POR, PWM, and WDT, along with 70 I/O pins. The device supports analog functions with an 8x10-bit ADC and 2x8-bit DAC.



Operating within a voltage range of 2.7V to 3.6V, the HD64F2319EVTE25 is suitable for a wide range of applications. It has an operating temperature range of -20°C to 75°C.



The component is housed in a 100-TQFP package, measuring 14x14mm, and is designed for surface mounting.

HD64F2319EVTE25 Quick Information

Product Type: Microcontroller
Series: H8S/2319
Canonical Name: Renesas HD64F2319EVTE25 16-bit Microcontroller
Subcategory: Embedded Microcontrollers

HD64F2319EVTE25 Compliance

RoHS Status: RoHS Compliant
Moisture Sensitivity Level (MSL): 1 Unlimited
REACH Status: REACH Unaffected

HD64F2319EVTE25 Estimated Pricing

Qty Low High
1+ $2.50 $2.50

Estimated market price range - modelled values for guidance only, not live distributor offers.

HD64F2319EVTE25 Features

  • 16-bit H8S/2300 series microcontroller.
  • Operates at a 25MHz clock frequency.
  • Features 512KB Flash and 8KB RAM.
  • Includes SCI, POR, PWM, and WDT peripherals.
  • Packaged in a 100-TQFP surface mount.

HD64F2319EVTE25 Applications

  • Suitable for embedded control systems.
  • Ideal for applications requiring 16-bit processing.
  • Used in devices with moderate memory needs.
  • Designed for general-purpose embedded tasks.

HD64F2319EVTE25 FAQs

7 frequently asked questions generated from this part’s specifications.
What is the operating voltage range of the HD64F2319EVTE25?

2.7V to 3.6V.

What is the package type?

100-TQFP.

What is the operating temperature range?

-20°C to 75°C.

What is the maximum frequency?

25 MHz.

How much flash memory does it have?

512 KB.

How many I/O pins does it have?

70.

Does it have an analog-to-digital converter?

Yes, 8-channel 10-bit ADC.
