| Category | |
| Manufacturer Name | |
| Applications | |
| Approval Agency | |
| Current | |
| Efficiency | |
| Features | |
| Height | |
| Input Voltage | |
| Length | |
| Mounting Type | |
| Number of Outputs | |
| Operating Temperature | |
| Output Voltage | |
| Power (Watts) | |
| Stability | |
| Storage Temperature | |
| Temperature Coefficient | |
| Type | |
| Voltage | |
| Width |
This linear AC DC converter from SL Power Electronics, part number HD5-12-OV-A+G, provides a stable 5V output with a maximum current of 12A, totaling 60W of power. It operates with an efficiency of 45% and accepts a universal input voltage range of 100 to 240 VAC.
The unit is designed for chassis mounting and includes features such as adjustable output and remote sense capabilities. Its operating temperature range is 0°C to 70°C with derating. The converter is approved by CE, cURus, and TUV, making it suitable for ITE (Commercial) applications.
Key specifications include a line regulation of ±0.05% and a load regulation of ±0.05%. It also features automatic current limit/foldback for short circuit protection and built-in overvoltage protection on 5V models. The datasheet indicates a typical MTBF of over 200,000 hours.
The output voltage is 5V.
The maximum output current is 12A.
The power rating is 60W.
The efficiency is 45%.
The operating temperature range is 0°C to 70°C with derating.
It is designed for chassis mount installations.
Key features include adjustable output, remote sense, and universal input.
