The SL Power Electronics HD48-3-A+G is a linear AC/DC power supply designed for ITE (Commercial) applications. It offers a single 48V output with a current rating of 4A, resulting in a total power output of 144W.
This converter accepts a universal input voltage range of 100 to 240 VAC. Key features include adjustable output, remote sense capability, and chassis mounting for integration into various systems. The operating temperature range is specified from 0°C to 70°C with derating.
Compliance is indicated by CE, cURus, and TUV approvals. The unit dimensions are 228.6mm in length, 124.0mm in width, and 69.9mm in height. It is designed for reliable operation with features like automatic current limit/foldback for short circuit protection.
The output voltage is 48V.
The maximum output current is 4A.
The power rating is 144W.
It is a linear AC/DC converter.
The input voltage range is 100 to 240 VAC.
The operating temperature range is 0°C to 70°C with derating.
It uses chassis mount.
