HD3SS460IRNHR The Texas Instruments HD3SS460IRNHR is a 4x6-channel USB Type-C Alternate Mode multiplexer/demultiplexer. It supports USB 3.2 Gen 1x1 and DisplayPort 1.2a protocols.
Mfr Part #:

HD3SS460IRNHR

Available from 3 distributors
Mfr Name: Texas Instruments
Texas Instruments
The Texas Instruments HD3SS460IRNHR is a 4x6-channel USB Type-C Alternate Mode multiplexer/demultiplexer. It supports USB 3.2 Gen 1x1 and DisplayPort 1.2a protocols.
✓ Total Stock: 554,958 pcs
$ Price Range: $1.21

HD3SS460IRNHR Available from 3 distributors

✓ Authorised
✓ Non-Authorised
Distributor Stock Pricing MOQ PKG Lead Time Date Code On Order Quantity On Order Delivery
Unit Electronics Co.,Limited ✓
Non-Authorised Inventory information
548,577 pcs
On Request
548577 pcs On Request 1 On Request On Request On Request On Request On Request
Optech Co.,Limited ✓
Non-Authorised Inventory information
5,581 pcs
On Request
5581 pcs On Request 1 On Request On Request 21+ On Request On Request
Xingangxin ✓
Non-Authorised Inventory information
800 pcs
On Request
800 pcs On Request 1 On Request On Request On Request On Request On Request
DistyParts aggregates offers from multiple distributors. Final prices, lead times and terms are subject to the distributors' discretion and may change without prior notice. DistyParts is not liable for any discrepancies.

HD3SS460IRNHR Specifications Quick View

Most important parameters for selection – full specs in datasheet.
Category
Manufacturer Name
AEC Qualified
Applications
Automotive Grade
Bandwidth
Configuration
Features
Frequency
Industrial Grade
Lead Spacing
Medical Grade
Military Grade
Mounting Type
Multiplexer
Number of Channels
On
Operating Temperature
Supplier Device Package
Voltage
View Similar Products (0)

HD3SS460IRNHR Description

Short technical summary and product information.

The Texas Instruments HD3SS460IRNHR is a high-speed, bi-directional passive switch designed for USB Type-C Alternate Mode applications. This 4x6 channel mux/demux supports configurations for source/host and sink/device roles.



Key electrical specifications include a USB speed of 5000 Mbps and a bandwidth of 2700 MHz. It operates with an input/output voltage range of 0 V to 2 V and features a typical on-resistance of 8000 mΩ. The device offers low power consumption with a typical supply current of 600 µA and includes ESD protection up to 4 kV HBM.



Designed for industrial applications, the HD3SS460IRNHR operates within an extended temperature range of -40°C to 85°C. It is available in a 30-WQFN package with surface mount mounting type.



This component is compatible with protocols such as DP1.2, USB 3.0, USB 3.2 Gen 1x1, and USB-C, making it suitable for a wide range of USB Type-C ecosystem solutions.

HD3SS460IRNHR Quick Information

Product Type: Analog Switch
Series: HD3SS460
Canonical Name: HD3SS460IRNHR USB Type-C Alternate Mode Mux/Demux
Subcategory: Special Purpose

HD3SS460IRNHR Compliance

RoHS Status: RoHS Compliant
Moisture Sensitivity Level (MSL): 1 Unlimited
REACH Status: REACH Unaffected

HD3SS460IRNHR Estimated Pricing

Qty Low High
1+ $1.21 $1.21

Estimated market price range - modelled values for guidance only, not live distributor offers.

HD3SS460IRNHR Features

  • 4x6 channel USB Type-C Alternate Mode mux/demux.
  • Supports 5000 Mbps USB 3.2 Gen 1x1 speed.
  • Features 2700 MHz bandwidth for high-speed data.
  • Operates across -40°C to 85°C industrial temperature range.
  • Surface mount 30-WQFN package for easy integration.

HD3SS460IRNHR Applications

  • Enables USB Type-C Alternate Mode functionality.
  • Suitable for USB host and device applications.
  • Supports DisplayPort 1.2a video signals.
  • Used in USB-C enabled systems and peripherals.

HD3SS460IRNHR FAQs

6 frequently asked questions generated from this part’s specifications.
What is the operating temperature range for the HD3SS460IRNHR?

The operating temperature range is -40°C to 85°C.

What package type is the HD3SS460IRNHR available in?

The HD3SS460IRNHR is available in a 30-WQFN (4.5x2.5) package.

What are the supported protocols for the HD3SS460IRNHR?

It supports DP1.2, USB 3.0, USB 3.2 Gen 1x1, and USB-C protocols.

What is the typical on-resistance of the HD3SS460IRNHR?

The typical on-resistance is 8000 mΩ.

What is the USB speed supported by this device?

The device supports a USB speed of 5000 Mbps.

What is the bandwidth of the HD3SS460IRNHR?

The bandwidth is 2700 MHz.
