The Broadcom HCPL-7800-000E is an active isolation amplifier designed for single-channel applications. It operates at a 5V supply voltage and provides a high isolation voltage of 3.75kV, making it suitable for applications requiring electrical isolation.
Key electrical characteristics include a common mode rejection ratio of 76dB and a bandwidth extending to 100kHz. The amplifier has an input current of 16mA and an output current per channel of 16mA. It features a low input bias current of 500nA and an input offset voltage of 300µV.
This component is packaged in an 8-pin PDIP for through-hole mounting. It operates within a temperature range of -40°C to 85°C and is RoHS compliant.
The HCPL-7800-000E is ideal for applications requiring reliable signal isolation, such as in power supply monitoring, motor control, and industrial automation systems.
| Qty | Low | High |
|---|---|---|
| 1+ | $0.36 | $0.36 |
Estimated market price range - modelled values for guidance only, not live distributor offers.
The isolation voltage is 3.75kV.
The bandwidth is 100kHz.
The operating voltage is 5V.
The operating temperature range is -40°C to 85°C.
It is packaged in an 8-pin PDIP for through-hole mounting.
