HCPL-4502-320E The Broadcom Limited HCPL-4502-320E is a digital isolator designed for robust signal isolation. It offers high isolation voltage and a wide operating temperature range.
Mfr Part #:

HCPL-4502-320E

Available from 1 distributors
Mfr Name: Broadcom Limited
Broadcom Limited
The Broadcom Limited HCPL-4502-320E is a digital isolator designed for robust signal isolation. It offers high isolation voltage and a wide operating temperature range.
✓ Total Stock: 550 pcs
$ Price Range: $4.30

HCPL-4502-320E Available from 1 distributor

✓ Authorised
✓ Non-Authorised
Distributor Stock Pricing MOQ PKG Lead Time Date Code On Order Quantity On Order Delivery
Flip Electronics ✓
Non-Authorised Inventory information
550 pcs
On Request
550 pcs On Request 1 On Request On Request On Request On Request On Request
DistyParts aggregates offers from multiple distributors. Final prices, lead times and terms are subject to the distributors' discretion and may change without prior notice. DistyParts is not liable for any discrepancies.

HCPL-4502-320E Specifications Quick View

Most important parameters for selection – full specs in datasheet.
Category
Manufacturer Name
Forward Current
Forward Voltage
Mounting Type
Operating Temperature
Output Current
Propagation Delay
Reverse Voltage
View Similar Products (0)

HCPL-4502-320E Description

Short technical summary and product information.

The Broadcom Limited HCPL-4502-320E is a digital isolator that provides reliable isolation between circuits. It features a high isolation voltage rating of 3750Vrms, ensuring strong isolation for system safety and performance.



This optocoupler operates with a typical forward voltage of 1.5V and a maximum forward current of 25mA. The current transfer ratio (CTR) ranges from 19% to 50% at 16mA. It offers a propagation delay between 200ns and 600ns.



The HCPL-4502-320E is designed for a wide operating temperature range, from -55°C to 100°C, making it suitable for demanding industrial environments. It has a maximum reverse voltage of 20V and a maximum output current of 8mA.



Packaged in an 8-DIP through-hole configuration, this component is suitable for standard PCB mounting. Its robust design makes it a reliable choice for applications requiring signal isolation.

HCPL-4502-320E Quick Information

Product Type: Digital Isolator
Canonical Name: HCPL-4502-320E Digital Isolator
Subcategory: Digital Isolators

HCPL-4502-320E Compliance

RoHS Status: RoHS Compliant
Moisture Sensitivity Level (MSL): 1 Unlimited
REACH Status: REACH Unaffected

HCPL-4502-320E Estimated Pricing

Qty Low High
1+ $4.30 $4.30

Estimated market price range - modelled values for guidance only, not live distributor offers.

HCPL-4502-320E Features

  • 3750Vrms isolation voltage rating.
  • CTR range of 19% to 50% at 16mA.
  • Wide -55°C to 100°C operating temperature.
  • 200ns to 600ns propagation delay.
  • 8-DIP through-hole package.

HCPL-4502-320E Applications

  • Provides robust signal isolation.
  • Suitable for demanding industrial environments.
  • Ensures system safety and performance.
  • Used in applications requiring high voltage separation.

HCPL-4502-320E FAQs

5 frequently asked questions generated from this part’s specifications.
What is the maximum isolation voltage of the HCPL-4502-320E?

3750 Vrms

What is the typical propagation delay of this digital isolator?

200 ns to 600 ns

What is the operating temperature range for the HCPL-4502-320E?

-55°C to 100°C

What package type is used for this component?

8-DIP

Is the HCPL-4502-320E RoHS compliant?

Yes, it is RoHS3 compliant.
