The HCPL-2232-500E from Broadcom Limited is a logic output optoisolator designed for reliable signal isolation in various electronic systems. It provides 3.75kVrms of isolation, ensuring protection between circuits. The device supports a data rate of 5MBd and operates with a push-pull, totem pole output type.
This optoisolator features 2 input channels and operates with a DC input type. It has a wide operating temperature range of -40°C to 85°C, making it suitable for diverse environmental conditions. The component is housed in a surface mountable 8-SMD, Gull Wing package, facilitating integration into compact designs.
Key electrical characteristics include a minimum common mode transient immunity of 10kV/µs and a current rating of 10mA. The propagation delay (tpLH) is specified at 300ns. The HCPL-2232-500E is designed for applications requiring robust isolation and signal integrity.
| Qty | Low | High |
|---|---|---|
| 1+ | $2.14 | $2.14 |
Estimated market price range - modelled values for guidance only, not live distributor offers.
The HCPL-2232-500E operates between -40°C and 85°C.
The HCPL-2232-500E is available in an 8-SMD, Gull Wing package.
The HCPL-2232-500E provides 3750Vrms of isolation.
The HCPL-2232-500E supports a data rate of 5MBd.
The HCPL-2232-500E features 2 channels.
The HCPL-2232-500E has a minimum common mode transient immunity of 10kV/µs.
The propagation delay (tpLH) for the HCPL-2232-500E is 300ns.
