| Distributor | Stock | Pricing | MOQ | PKG | Lead Time | Date Code | On Order Quantity | On Order Delivery | |
|---|---|---|---|---|---|---|---|---|---|
|
2,700 pcs
|
2700 pcs | On Request | 1 | On Request | On Request | On Request | On Request | On Request | |
|
45 pcs
|
45 pcs | On Request | 1 | On Request | On Request | On Request | On Request | On Request |
| Category | |
| Manufacturer Name | |
| Current | |
| Current Rating (Amps) | |
| DC Resistance (DCR) | |
| Height | |
| Inductance | |
| Length | |
| Material | |
| Mounting Type | |
| Operating Temperature | |
| SVHC Present | |
| Shielding | |
| Tolerance | |
| Type | |
| Width |
The HC9-100-R is a wirewound drum core inductor from Eaton's Electronics Division. It offers an inductance of 10µH with a tolerance of ±15% and a DC current rating of 8.5A. The saturation current is 12.5A. The inductor features a low DC resistance of 14mOhm maximum, making it suitable for power applications where efficiency is important. The component is unshielded and uses an iron powder core, providing good performance at high temperatures up to 155°C. It is surface mounted in a nonstandard package measuring 14.10mm x 13.10mm x 7.50mm. This inductor is RoHS3 compliant and has a moisture sensitivity level of 1.
10 µH.
8.5 A DC.
14 mOhm maximum.
12.5 A.
±15%.
-40°C to 155°C.
Nonstandard surface mount package, dimensions 14.10mm x 13.10mm x 7.50mm.
