HA-003 The Beisit Electric HA-003 is a male heavy-duty connector with 3 contacts, designed for robust industrial applications. It offers a 10A rated current and 250V rated voltage.
Mfr Part #:

HA-003

Available from 1 distributors
Mfr Name: NA
NA
The Beisit Electric HA-003 is a male heavy-duty connector with 3 contacts, designed for robust industrial applications. It offers a 10A rated current and 250V rated voltage.
✓ Total Stock: 20,840 pcs
$ Price Range: $1.17

HA-003 Available from 1 distributor

✓ Authorised
✓ Non-Authorised
Distributor Stock Pricing MOQ PKG Lead Time Date Code On Order Quantity On Order Delivery
PROSOFT ELECTRONICS ✓
Non-Authorised Inventory information
20,840 pcs
On Request
20840 pcs On Request 1 On Request On Request 05+ On Request On Request
DistyParts aggregates offers from multiple distributors. Final prices, lead times and terms are subject to the distributors' discretion and may change without prior notice. DistyParts is not liable for any discrepancies.

HA-003 Specifications Quick View

Most important parameters for selection – full specs in datasheet.
Category
Manufacturer Name
Contact Resistance
Insulation Resistance
Material
Number of Contacts
Operating Temperature
Rated Current
SVHC Present
Termination Style
Voltage
View Similar Products (0)

HA-003 Description

Short technical summary and product information.

The Beisit Electric HA-003 is a male heavy-duty connector designed for reliable power transmission in demanding industrial environments. It features a 3-contact configuration and a male head connection type, utilizing screw terminals for secure wiring.



This connector boasts a rated current of 10A and a rated voltage of 250V, with a higher rated impulse voltage of 4KV. The insulation resistance is rated at a high ≥10¹⁰ Ω, ensuring signal integrity. The insert is made of durable Polycarbonate (PC) in RAL 7032 (Pebble Ash) color, while the pins are constructed from a copper alloy with silver/gold plating for optimal conductivity.



Operating within a wide temperature range of -40℃ to +125℃, the HA-003 is built to withstand harsh conditions. It meets UL94 V0 flame retardant standards and has a mechanical working life of ≥500 mating cycles. The conductor cross-sectional area accommodates 1.0-2.5mm² or AWG 18-14 wires, with a strip length of 7.5mm and a tightening torque of 0.5 Nm.



Suitable for applications requiring robust and pluggable electrical connections, such as rail transit, power engineering, and smart manufacturing, the HA-003 ensures fast and reliable connections even in harsh ambient conditions.

HA-003 Quick Information

Product Type: Heavy-Duty Connector
Series: A
Canonical Name: HA-003 Male Heavy-Duty Connector
Subcategory: Male Contact

HA-003 Compliance

RoHS Status: RoHS Compliant
Moisture Sensitivity Level (MSL): 1 Unlimited
REACH Status: REACH Unaffected

HA-003 Estimated Pricing

Qty Low High
1+ $1.17 $1.17

Estimated market price range - modelled values for guidance only, not live distributor offers.

HA-003 Features

  • Male heavy-duty connector with 3 contacts.
  • Rated for 10A current and 250V voltage.
  • Polycarbonate insert material for durability.
  • Screw terminal connection for secure wiring.
  • Wide operating temperature range of -40°C to +125°C.

HA-003 Applications

  • Ideal for industrial power connections.
  • Suitable for automation and machinery.
  • Used in rail transit applications.
  • Reliable for smart manufacturing systems.

HA-003 FAQs

6 frequently asked questions generated from this part’s specifications.
What is the rated current for the Beisit Electric HA-003 connector?

The rated current for the HA-003 connector is 10A.

What is the rated voltage of the HA-003 heavy-duty connector?

The rated voltage is 250V, with a rated impulse voltage of 4KV. It is also rated for 600V according to UL/CSA standards.

What is the operating temperature range for the HA-003 connector?

The operating temperature range is -40℃ to +125℃.

What material is the insert of the HA-003 connector made from?

The insert material is Polycarbonate (PC).

How many contacts does the HA-003 connector have?

The HA-003 connector has 3 contacts, plus a ground pin.

What type of connection does the HA-003 use?

The HA-003 uses screw terminals for connection.
