The H3161-05 is a straight through-hole female receptacle PCB socket from Harwin, designed to interface components with Ø1.00mm pins to printed circuit boards. It accepts pins from 0.89mm to 1.05mm in diameter. The socket features a gold finish on both the contact area and termination, with a contact finish thickness of 5.90µin (0.150µm). Its total length is 5.25mm and the flange diameter measures 2.34mm. A knurled body provides mechanical board retention; soldering is still required for the electrical connection. The socket is rated for a maximum current of 10.0A at 25°C ambient and 7.5A at 85°C ambient. Contact resistance is 10mΩ initial and 25mΩ after conditioning. It is rated for at least 1000 operations with gold finish. The operating temperature range is -55°C to +125°C. The socket meets environmental classification 55/125/21 and has been tested to withstand vibration from 10Hz to 2000Hz at 10G for 6 hours. Insertion force with a 1.00mm pin is maximum 9.0N; withdrawal force is minimum 1.0N.
| Qty | Low | High |
|---|---|---|
| 1+ | $0.57 | $0.57 |
| 10+ | $0.43 | $0.43 |
| 100+ | $0.37 | $0.37 |
| 500+ | $0.36 | $0.36 |
| 1,000+ | $0.35 | $0.35 |
| 2,000+ | $0.33 | $0.33 |
| 10,000+ | $0.32 | $0.32 |
Estimated market price range - modelled values for guidance only, not live distributor offers.
Maximum 10.0A at 25°C ambient and 7.5A at 85°C ambient.
It accepts pin diameters from 0.035" to 0.041" (0.89mm to 1.05mm).
At least 1000 operations with gold finish on the contact area.
-55°C to +125°C.
Yes, soldering is required for the electrical connection; the knurled body provides mechanical retention.
Initial contact resistance is 10mΩ maximum; after conditioning it is 25mΩ maximum.
2.34mm (0.092").
