| Distributor | Stock | Pricing | MOQ | PKG | Lead Time | Date Code | On Order Quantity | On Order Delivery | |
|---|---|---|---|---|---|---|---|---|---|
|
428 pcs
|
428 pcs | On Request | 1 | On Request | On Request | On Request | On Request | On Request |
| Category | |
| Manufacturer Name | |
| Accepts Pin Diameter | |
| Contact Finish | |
| Contact Finish Thickness | |
| Contact Material | |
| Flange Diameter | |
| Lead Spacing | |
| Lead Style | |
| Length | |
| Mounting Hole Diameter | |
| Mounting Type | |
| Overall Length | |
| Pin Hole Diameter | |
| Shoulder Height | |
| Socket Depth | |
| Tail Type | |
| Tape & Reel | |
| Termination | |
| Termination Style |
The Harwin H3153-01 is a female receptacle socket connector designed for through-hole PCB mounting. It accepts mating pin diameters ranging from 0.018" to 0.020" (0.46mm to 0.51mm), making it suitable for sub-miniature pin connections. The contact is made of beryllium copper with a gold finish, providing reliable electrical performance and corrosion resistance. The contact finish thickness is 3.94µin (0.10µm).
This straight (vertical) socket has an overall length of 3.56mm, a socket depth of 0.124" (3.15mm), and a shoulder height of 0.38mm. The flange diameter is 1.45mm (0.057"), and the pin hole diameter is 0.043" (1.09mm). The mounting hole diameter range is 0.039" to 0.043" (0.99mm to 1.09mm). The part has no tail and requires soldering to the PCB for electrical connection.
| Qty | Low | High |
|---|---|---|
| 1+ | $0.41 | $0.41 |
| 10+ | $0.33 | $0.33 |
| 100+ | $0.28 | $0.28 |
| 500+ | $0.26 | $0.26 |
| 1,000+ | $0.25 | $0.25 |
Estimated market price range - modelled values for guidance only, not live distributor offers.
The H3153-01 accepts pin diameters from 0.018" to 0.020" (0.46mm to 0.51mm).
The H3153-01 is a through-hole mounting component with solder termination.
The contact material is beryllium copper with a gold finish. The contact finish thickness is 3.94µin (0.10µm).
The overall length is 3.56mm.
