H11L1 The Isocom Components H11L1 is a logic output optoisolator featuring 5000VRMS isolation and a 1MHz data rate. It is designed for through-hole mounting in a 6-DIP package.
Mfr Part #:

H11L1

Available from 3 distributors
Mfr Name: Isocom Components
Isocom Components
The Isocom Components H11L1 is a logic output optoisolator featuring 5000VRMS isolation and a 1MHz data rate. It is designed for through-hole mounting in a 6-DIP package.
✓ Total Stock: 10,871 pcs
$ Price Range: $0.50

H11L1 Available from 3 distributors

✓ Authorised
✓ Non-Authorised
Distributor Stock Pricing MOQ PKG Lead Time Date Code On Order Quantity On Order Delivery
Optech Co.,Limited ✓
Non-Authorised Inventory information
6,931 pcs
On Request
6931 pcs On Request 1 On Request On Request 02+ On Request On Request
Components Technology Group, Inc. ✓
Non-Authorised Inventory information
3,200 pcs
On Request
3200 pcs On Request 1 On Request On Request On Request On Request On Request
HMB Electronics LLC ✓
Non-Authorised Inventory information
740 pcs
On Request
740 pcs On Request 1 On Request On Request On Request On Request On Request
DistyParts aggregates offers from multiple distributors. Final prices, lead times and terms are subject to the distributors' discretion and may change without prior notice. DistyParts is not liable for any discrepancies.

H11L1 Specifications Quick View

Most important parameters for selection – full specs in datasheet.
Category
Manufacturer Name
Current
Data Rate
Forward Voltage
Input Type
Inputs
Lead Spacing
Mounting Type
Number of Channels
Operating Temperature
Operating Voltage
Output Type
Propagation Delay tpLH
Reverse Current
Rise
Supplier Device Package
Supply Current
Voltage
View Similar Products (0)

H11L1 Description

Short technical summary and product information.

The Isocom Components H11L1 is an optoisolator designed for logic-to-logic isolation applications. It features a GaAs infrared emitting diode coupled to a high-speed output integrated Schmitt trigger detector, providing hysteresis for noise immunity and pulse shaping. This device offers a typical data rate of 1MHz and an isolation voltage of 5000VRMS.



Key electrical specifications include an operating voltage range of 3V to 15V and an open collector output type. The optoisolator has a typical supply current of 5mA and a high-level output current of 100µA. It supports DC input and has a typical rise time of 100ns and propagation delay of 6µs.



The H11L1 is suitable for applications such as line receivers, AC to TTL conversion, and power supply digital programming. It is housed in a 6-DIP package for through-hole mounting, with an operating temperature range of -25°C to 85°C.

H11L1 Quick Information

Product Type: Optoisolator
Canonical Name: H11L1 Optoisolator - Logic Output
Subcategory: Logic Output

H11L1 Compliance

RoHS Status: RoHS Compliant
Moisture Sensitivity Level (MSL): 1 Unlimited
REACH Status: REACH Unaffected

H11L1 Estimated Pricing

Qty Low High
1+ $0.50 $0.50

Estimated market price range - modelled values for guidance only, not live distributor offers.

H11L1 Features

  • 5000VRMS high AC isolation voltage.
  • 1MHz typical data rate (NRZ).
  • Microprocessor compatible Schmitt trigger output.
  • Open collector output sinks 16mA.
  • Through hole mounting, 6-DIP package.

H11L1 Applications

  • Logic to logic isolator.
  • Line receiver for noise elimination.
  • AC to TTL conversion.
  • Square wave shaping.

H11L1 FAQs

7 frequently asked questions generated from this part’s specifications.
What is the operating voltage range for the H11L1?

The operating voltage range for the H11L1 is 3V to 15V.

What type of package is the H11L1 in?

The H11L1 is available in a 6-DIP package.

What is the operating temperature range for the H11L1?

The operating temperature range for the H11L1 is -25°C to 85°C.

What is the RoHS status of the H11L1?

The H11L1 is RoHS3 Compliant.

What is the typical data rate of the H11L1 optoisolator?

The H11L1 optoisolator has a typical data rate of 1MHz.

What is the isolation voltage of the H11L1?

The H11L1 provides 5000VRMS of AC isolation voltage.

What is the output type of the H11L1?

The H11L1 features an open collector output type.
