| Category | |
| Manufacturer Name | |
| Applications | |
| Approval Agency | |
| Cord Length | |
| Current | |
| Efficiency | |
| Form | |
| Height | |
| Input Connector | |
| Input Type | |
| Length | |
| No Load Power Consumption | |
| Operating Temperature | |
| Output Connector | |
| Polarization | |
| Power (Watts) | |
| Region Utilized | |
| SVHC Present | |
| Voltage | |
| Width |
The Mean Well USA GST40A24-P2JR is a versatile AC/DC desktop adapter designed for ITE (Commercial) applications. It delivers a stable 24V output with a maximum current of 1.67A, providing a total power of 40W. This adapter adheres to Level VI efficiency standards, ensuring energy conservation.
The unit features a standard IEC 320-C14 input connector and a barrel plug output connector (2.1mm I.D. x 5.5mm O.D. x 11.0mm) with a positive center polarization. Its compact dimensions are 125.0mm x 50.0mm x 31.5mm, making it suitable for various setups. The operating temperature range is from -30°C to 70°C, offering reliability in diverse environmental conditions.
Designed for international use, the GST40A24-P2JR complies with numerous approval agency standards including BIS, BSMI, CB, CCC, CE, cULus, EAC, GS, KC, PSE, RCM, and SIRIM. It operates with a low no-load power consumption of 75mW (Max). The input cord is sold separately and has a length of 70.9" (1.80m).
The output voltage is 24V and the output current is 1.67A.
The power rating is 40W.
It accepts a universal input of 100-240 VAC.
The operating temperature range is -30°C to 70°C.
It has a right-angle barrel plug with 2.1mm inner diameter and 5.5mm outer diameter.
It meets Level VI efficiency.
