This Mean Well USA GST25A24-P1M is a 25W AC/DC desktop power adapter designed for ITE (Commercial) applications. It delivers a stable 24V output at 1.04A, meeting the stringent Level VI energy efficiency requirements.
The adapter operates across a wide temperature range from -30°C to 70°C, making it suitable for various environmental conditions. It features an IEC 320-C14 input connector and a standard barrel plug output (2.5mm I.D. x 5.5mm O.D. x 11.0mm) with positive center polarization.
With dimensions of 93.0mm x 54.0mm x 36.0mm, this desktop adapter offers a compact form factor. It is designed for international use and includes features like low no-load power consumption (75mW Max) and RoHS3 compliance.
The output is 24 VDC at 1.04A, providing 25W of power.
The input voltage range is 100-240 VAC.
It meets Level VI efficiency standards.
The operating temperature range is -30°C to 70°C.
It has a barrel plug with 2.5mm I.D. x 5.5mm O.D. x 11.0mm dimensions, positive center polarity.
The no load power consumption is 75mW maximum.
